9.1
Pressure loss curve
Test made at 20°C (water)
Tolerance ± 5%
9.2
Dependency on maximum permitted pressure and temperature
9.3
Technical data
FMC 100/PP FMC 100/ETFE
Flow rate
Pressure range
(max. nominal
pressure)
Viscosity
Liquid temperature
Accuracy
Weight
Housing
Mate-
Measu-
rial
ring
chamber
1
Q [L/min)
Stainless Steel
Stainless steel
10 - 100 l/min*
0.1 - 4 bar max.
(at water 20°C)
Up to 60°C at max. 2 bar
± 1%
1.1 kg
1.4 kg
PP
ETFE
PPS
ETFE
* Smaller flow volumes on request
Operating instructions FMC
1 FMC 100
2
2 FMC 250
T [°C]
FMC 100/S
FMC 250/PP
0.1 - 6 bar
0.1 - 6 bar max.
max.
Up to 2500 mPas
Up to 80°C
± 1% between 50 l/min and
1.7 kg
4.5 kg
Stainless
PP
Steel 316 Ti
PPS
PE
FMC 250/PVDF
30 - 250 l/min
Up to 60°C
250 l/min
9.0 kg
PVDF
PVDF
27 / 60
