If the plug is not suitable for your socket outlets, it should be
cut off and an appropriate plug fitted in its place by an author-
ised customer service agent. The replacement plug should
have the same fuse rating as the original plug.
The severed plug must be disposed of to avoid a possible
shock hazard and should never be inserted into a mains sock-
et elsewhere.
Products sold in AUS and NZ only: Use a residual current de-
vice (RCD) with a rated residual current of 30 mA or less.
Product Description and Specifica-
tions
Read all safety warnings and all instruc-
tions. Failure to follow the warnings and in-
structions may result in electric shock, fire
and/or serious injury.
Intended Use
The machine is intended for cutting, roughing and brushing of
metal and stone materials without the use of water.
For cutting with bonded abrasives, a special cutting guard
(accessory) must be used.
When cutting in stone, provide for sufficient dust extraction.
With approved sanding tools, the machine can be used for
sanding with sanding discs.
Product Features
The numbering of the product features refers to the illustra-
tion of the machine on the graphics page.
Technical Data
Angle Grinder
Article number
Rated power input
Output power
Rated speed
Grinding disc diameter, max.
Thread of grinder spindle
Thread length (max.) of grinder spindle
Speed preselection
Weight according to EPTA-Procedure 01/2003
Protection class
Bosch Power Tools
1 Spindle lock button
2 On/Off switch
3 Thumbwheel for speed preselection (GWS 6-100 E/
GWS 6-115 E/GWS 6-125 E)
4 Auxiliary handle (insulated gripping surface)
5 Combination spanner for M 14 grinder spindle*
6 Combination spanner for M 10 grinder spindle*
7 Grinder spindle
8 Protection guard for grinding
9 Locking screw for protection guard
10 Mounting flange with O-ring
11 Grinding wheel*
12 Clamping nut
13 Quick-clamping nut
14 Carbide grinding head*
15 Protection guard for cutting*
16 Cutting disc*
17 Hand guard*
18 Rubber sanding plate*
19 Sanding sheet*
20 Round nut*
21 Cup brush*
22 Cutting guide with dust extraction protection guard *
23 Diamond cutting disc*
24 Handle (insulated gripping surface)
25 Direction-of-rotation arrow on housing
*Accessories shown or described are not part of the standard de-
livery scope of the product. A complete overview of accessories
can be found in our accessories program.
GWS... 5-100 580
0 601 ... 376 0.. 376 0..
W 580 580
W 300 300
-1
min 11000 11000
mm 100 100
M 10 M 10
mm 17 17
– –
kg 1.8 1.8
/II /II
English | 9
*
5-115 670 6-100
376 2.. 375 0.. 375 0..
580 670 670
300 400 400
11000 11000 11000
115 100 100
M 14 M 10 M 10
22 17 17
– – –
1.9 1.8 1.8
/II /II /II
