Angle Grinder
Article number
Rated power input
Output power
Rated speed
Speed control adjustment
Grinding disc diameter, max.
Thread of grinder spindle
Thread length (max.) of grinder spindle
Speed preselection
Weight according to EPTA-Procedure 01/2003
Protection class
The values given are valid for a nominal voltage [U] of 230 V. For different voltages and models for specific countries, these values can vary.
Assembly
Mounting the Protective Devices
 Before any work on the machine itself, pull the mains
plug.
Note: After breakage of the grinding disc during operation or
damage to the holding fixtures on the protection guard/power
tool, the machine must promptly be sent to an after-sales ser-
vice agent for maintenance. For addresses, see section "Af-
ter-sales Service and Application Service".
Protection Guard for Grinding
Place the protection guard 8 on the spindle collar. Adjust the
position of the protection guard 8 to the requirements of the
operation. Lock the protection guard 8 tightening the locking
screw 9 with a screwdriver.
 Adjust the protection guard 8 in such a manner that
sparking is prevented in the direction of the operator.
Note: The encoding keys on the protection guard 8 ensure
that only a protection guard that fits the machine type can be
mounted.
Protection Guard for Cutting
 For cutting with bonded abrasives, always use the pro-
tection guard for cutting 15.
 Provide for sufficient dust extraction when cutting
stone.
The protection guard for cutting 15 is mounted in the same
manner as the protection guard for grinding 8.
Cutting Guide with Dust Extraction Protection Guard
The cutting guide with dust extraction protection guard 22 is
mounted in the same manner as the protection guard for
grinding 8.
Auxiliary Handle
 Operate your machine only with the auxiliary handle 4.
Screw the auxiliary handle 4 on the right or left of the machine
head depending on the working method.
1 619 P12 265 | (12.6.14)
GWS... 6-100 E 6-115
0 601 ... 375 7.. 375 0..
W 670 670
W 400 400
-1
min 11000 11000
-1
min 2800 –
– 11000
mm 100 115
M 10 M 14
mm 17 22

–
kg 1.8 1.9
/II /II
Hand Guard
 For operations with the rubber sanding plate 18 or with
the cup brush/wheel brush/flap disc, always mount the
hand guard 17.
The hand guard 17 is fastened with the auxiliary handle 4.
Mounting the Grinding Tools
 Before any work on the machine itself, pull the mains
plug.
 Do not touch grinding and cutting discs before they
have cooled down. The discs can become very hot while
working.
Clean the grinder spindle 7 and all parts to be mounted.
For clamping and loosening the grinding tools, lock the grind-
er spindle with the spindle lock button 1.
 Actuate the spindle lock button only when the grinder
spindle is at a standstill. Otherwise, the machine may be-
come damaged.
Grinding/Cutting Disc
Pay attention to the dimensions of the grinding tools. The
mounting hole diameter must fit the mounting flange without
play. Do not use reducers or adapters.
When using diamond cutting discs, pay attention that the di-
rection-of-rotation arrow on the diamond cutting disc and the
direction of rotation of the machine (see direction-of-rotation
arrow on the machine head) agree.
See graphics page for the mounting sequence.
To fasten the grinding/cutting disc, screw on the clamping nut
12 and tighten it with the combination spanner 5/6, (see sec-
tion "Quick-clamping Nut").
 After mounting the grinding tool and before switching
on, check that the grinding tool is correctly mounted
and that it can turn freely. Make sure that the grinding
tool does not graze against the protection guard or oth-
er parts.
6-115 E 6-125 6-125 E
375 5.. 375 1.. 375 9..
375 7..
375 9..
670 670 670
400 400 400
11000 11000 11000
2800 – 2800
– 11000 – 11000
115 125 125
M 14 M 14 M 14
22 22 22
 
–
1.9 1.9 1.9
/II /II /II
