Thule 821 LOW RIDER Mode D'emploi

1
Recommended Mounting
Hardware 1/4" or (6mm)
bolts or screws, fender
washers, and locking nuts.
3
5
821 LOW RIDER
Low Rider attaches securely
to flat surfaces.
• Align block with drilled holes.
• Tighten hardware securely.
Test installation by pulling
and shaking block.
• With lever open, tighten nut
until the lever closes with
some resistance.
• Loosen or tighten the nut as
needed so that lever closes
with some resistance.
DRILLING TEMPLATE
Drill 4 places using 5/16" or 8mm drill bit
2
4
• Set the bicycle forks onto the skewer.
Test security by tugging at forks. If forks can move out
of the skewer, open lever and tighten the nut slightly.
Close lever again with firm pressure. Repeat if necessary.
Use the template below to scribe four
drilling points.
• 5/16" (8mm) drill bit recommended.
• Always check handlebar
clearance before attaching
block.
