2 or 1 LED(s) lit:
The battery has an adequate remaining charge.
1 LED fl ashing:
The battery is empty, recharge the battery.
All LEDs fl ashing:
The temperature of the battery is too low. Remove
the battery from the device and leave it at room
temperature for a day. If the error occurs again,
this means that the battery has been completely
depth-discharged and is defective. Remove the
battery from the device. Never use or charge a
defective battery.
6.5 LED light (Fig. 1 / item 5)
The LED light (5) can be used in poor lighting
conditions to illuminate the area where you
want to screw. The LED light (5) comes on
automatically as soon as you press the On/Off
switch (4).
6.6 Changing the bit (Fig. 5)
Caution! Set the changeover switch (3) to its
center position whenever you carry out any work
(for example changing the tool, maintenance
work, etc.) on the impact wrench.
Fitting/removing a tool
Fit the required impact socket by pushing it onto
the square drive (1). Remove the impact socket
by pulling it off the square drive (1).
6.7 Selector switch setting 1-2-3 (Fig. 6/Item
2)
There are 3 settings for operating the cordless
impact wrench. This enables you to adjust the
speed and torque to the specifi c size of screw/
bolt.
To move from one setting to another, press briefl y
on the selector switch setting 1 - 2 - 3 (2).
The active setting of the impact wrench is
indicated by the 3 LED.
Setting 1: Low speed / torque
Setting 2: Medium speed / torque
Setting 3: Maximum speed / torque
Anl_Impaxxo_18_400_USA_SPK7.indb 12
Anl_Impaxxo_18_400_USA_SPK7.indb 12
EN
6.8 Working with the impact wrench
Loosening:
•
Fit the impact socket on the impact wrench
(see point 6.6).
•
Place the impact wrench on the screw/nut
and loosen the screw/nut by pressing the On/
Off switch (4).
•
If the screws/nuts are very tight or if they are
rusted, use a tire wrench or torque wrench to
slightly loosen them.
Tightening:
•
Warning! Use the impact wrench only for
loosening screws/nuts. If you want to use the
impact wrench to tighten screws and nuts,
you must also use a torque limiter which is
designed for this purpose. If not, the screw
connection may be damaged. The torque
limiter is available from your dealer. It is not
included in the scope of this delivery.
•
Prior to tightening, carefully insert the screw/
nut into the threads.
•
It is important that screws/nuts with special
torque specifications (for example provided
by the vehicle manufacturer in the automotive
sector) are tightened only with a suitable
torque limiter.
Danger!
Screws/nuts must be fi nish-tightened with a
torque wrench which is set to the torque specifi ed
by the manufacturer and then they must be
checked!
6.9 Removable holding clip
When the holding clip is fi tted, the equipment can
be hung e.g. on a belt. The removable holding clip
can be screw-fi tted to either the left or right-hand
side of the equipment. Fitting is possible but not
necessary.
