EU DECLARATION OF CONFORMITY
V2 SpA hereby declares that the products: RXP4-C
comply with the following directives:
2014/53/EU
ROHS2 2011/65/CE
The full declaration of conformity is available on the website
www.v2home.com in the section:
Products / Transmitters and Receivers / RXP4-C
DISPOSAL
As for the installation operations, even at the end of this
product's life span, the dismantling operations must be carried out
by qualified experts.
This product is made up of various types of materials:
some can be recycled while others need to be disposed of.
Find out about the recycling or disposal systems envisaged by
your local regulations for this product category.
Important! – Parts of the product could contain pollutants or
hazardous substances which, if released into the environment,
could cause harmful effects to the environment itself as well as
to human health.
As indicated by the symbol opposite, throwing away this product
as domestic waste is strictly forbidden. So dispose of it as
differentiated waste, in accordance with your local regulations,
or return the product to the retailer when you purchase a new
equivalent product.
Important! – the local applicable regulations may envisage
heavy sanctions in the event of illegal disposal of this product.
PRODUCT DESCRIPTION AND INTENDED USE
This decoder is part of the RXP4-C series by V2 SPA.
The decoders in this series are intended for controlling the
automation type door openers, gate openers and the like, lights
and electrical circuits in general.
Any other use is improper and prohibited!
Specifications:
• RXP4-C is a decoder with display, designed to interface the
proximity reader PROKSIMA or the digital keypad SIRMO-DIGIT
with other devices.
• By means of an appropriate input it receives the code
transmitted from the proximity reader or the digital keypad:
if it is on the stored codes, it will activate the respective relay
output.
• Programming via 3 buttons on display
• 4 programmable channels with three functions: mono-stable,
bistable and timer
• Relay 1 output with N.O. contact for charge up to 5A - 230Vac
• Relay 2 outputs 2 - 3 - 4 with N.O. or N.C. contact that can be
selected using the jumpers, for maximum charge up to 1A -
30Vdc
• Possibility to memorize 1008 different codes
• Programmable ROLLING CODE modes
• Saving data on MR2 removable receiver module
• Data management via PROG2 and WINPPLC by inserting the
removable module MR2 into connector TX of PROG2
All manuals and user guides at all-guides.com
TECHNICAL DATA
RELAY CONTACTS
Contacts connected to terminal board of the relay panel are of
normally open type (N.O.).
To obtain a normally close contact (N.C.) for relays 2,3,4 move the
relative jumpers (J2-J3-J4) to position 2.
NOTE: relay 1 contact can only be normally open (N.O.)
DISPLAY
When power is on, the control unit checks that display correctly
operates by switching on all segments for 1.5 sec.
Firmware version, e.g.
1.5 sec.
Panel will be viewed upon completion of this test :
PROGRAMMING
The programming of the functions and times of the unit is carried
out through the configuration menus, accessible and searchable
through the 3 buttons DOWN, MENU and UP placed next to the
display of the unit
To access the programming menu keep the MENU key pressed
until the first
• By pressing DOWN, you will pass to the next item
• By pressing UP, you will return to the previous item
• By pressing MENU, you can view the current value of selected
• Keep the keys UP and DOWN to scroll fast through the options
The last menu item (
and going back to the control unit normal operation.
You must exit from programming mode through this menu item if
you do not want to lose your configuration.
WARNING: in case no operation is carried out for more
than one minute, the control unit exits from the
programming mode without saving any of your setups and
changes, which will get lost
FAULT MESSAGES
Er 1
Er 2
Er 3
Er 4
- 6 -
Power supply
Relay contacts
Temperature
Consumption
Maximum data wire length
Size
Protection degree
Pr 1.0
, will be viewed in the following
r L
parameter is displayed
item and possibly change it
of configuration menu.
End
) allows storing the carried out changes
MR module faulty or inserted incorrectly
attempt to insert a code that is already saved in the
memory
memory full
programming blocked
12-24 Vac/dc / 12-36 Vdc
OUT1 = 5A - 230Vac
OUT2-3-4 = 1A - 30Vdc
-20 ÷ +60°C
16mA stand by
100 m
170 x 185 x 70 mm
IP55
8.8.8.8
.
- - - -
