STEP 1
Attach the adjustable
mounting brackets to the
frame using (4) #6 x 1/2" flat
head screws but keep them
loose to adjust. Hold the
frame to the cabinet door
and adjust the brackets to
the thicker part of the door
and tighten the screws (See
Figure 1).
2
STEP 2
Place the frame to the
desired position on the door
and mark the hole locations
and pre-drill pilot holes using
7/64" bit (See Fig. 2).
Note: Take care not to drill
through the door.
7
64
1
3
1
STEP 3
16
8
4
Align the brackets with the
holes and attach to door
using (4) #6 x 1/2" screws.
3
3
32
8
64
#2
#1
(See Figure 3).
2
5
#1
3
1
16
8
2
STEP 4
1
2
Attach the paper towel and
tear rod to door chassis (See
Figure 4).
2"
Note: Tear rod can be
installed on either side. Use
the included decorative cap
for the other hole.
2"
1"
Fig. 1
Fig. 3
1
1
4
8
3
7
1
32
64
8
7
5
5
8
16
Fig. 4
5
8
1"
90˚
90˚
Fig. 2
Adjustable mounting
brackets
Double check the height of the unit on the door to
ensure there is no interference
Adjustable mounting
brackets
Adjustable mounting
brackets
12400 Earl Jones Way
Louisville, KY 40299
rev-a-shelf.com
Customer Service: 800-626-1126
Mark screw locations
