O P E R A T I N G I N S T R U C T I O N S
Outdoor radio motion detector
"RSL"
Item no. 64 03 78
Use in accordance with manufacturer's instructions
With the outdoor radio motion detector an appropriate wireless remote-control switch of the
RSL system (or a load attached to it) can be switched on or off wirelessly.
The motion detector responds to temperature changes within the detection range, e.g. if a
person, an animal or a car enters the detection area.
Because of this, the motion detector is used for monitoring of entrances, stairs etc.
Any other use than that described above may damage the product. Moreover, this may give
rise to hazards such as short-circuiting, fi re, electric shock, etc. No part of the product may be
modifi ed or converted!
Always observe the safety instructions included in these operating instructions. Please read the
operating instructions carefully and store them.
This product complies with the applicable national and European requirements. All names of
companies and products are the trademarks of the respective owner. All rights reserved.
Package contents
• Outdoor radio motion detector with wall bracket
• Operating Instructions
Explanation of the Symbols
The exclamation mark indicates specifi c risks associated with handling, function and
use.
☞
The "Hand" symbol indicates special tips and operating information.
Safety Instructions
The warranty will be void in the event of damage caused by failure to observe
these safety instructions! We do not assume any liability for any consequen-
tial damage!
Nor do we assume any liability for material and personal damage caused by
improper use or non-compliance with the safety instructions! In such cases,
the warranty will be void!
• The unauthorised conversion and/or modifi cation of the product is not allowed for
safety and approval reasons (CE).
• The product is not a toy and should be kept out of the reach of children!
• Do not use this product in hospitals or medical institutions. Although the outdoor
radio motion detector emits only relatively weak radio signals, these may lead to
malfunction of life-support systems. The same may possibly be the case in other
areas.
• The product may be installed and used outdoors and indoors.
• Do not use this product in rooms or under adverse ambient conditions where com-
bustible gases, vapours or dust are or may be present! There is a risk of explosion!
• The product must not be exposed to extreme temperatures, strong vibrations or
heavy mechanical stress.
• Do not carelessly leave the packaging material lying around since it could become
a dangerous plaything for children.
• In commercial institutions, the accident prevention regulations of the employer's
liability insurance association for electrical systems and operating facilities are to
be observed!
• If you have any questions that are not answered in this manual, please contact our
technical service or another specialist.
All manuals and user guides at all-guides.com
Notes on batteries/rechargeable batteries
www.conrad.com
• Batteries/rechargeable batteries do not belong in the hands of children.
• Do not leave batteries/rechargeable batteries lying around; they could be swallowed by chil-
Version 06/11
• Leaking, or damaged batteries/rechargeable batteries, in contact with the skin can cause
• Batteries/rechargeable batteries must not be short-circuited, opened or thrown into a fi re.
• Do not recharge normal, non-rechargeable batteries, risk of explosion! Only charge re-
• If the product is not to be used for a while (e.g. storage), remove the batteries/rechargeable
• Check that the polarity is correct when inserting the batteries/rechargeable batteries (pay
• Always replace the whole set of batteries/rechargeable batteries. Do not mix fully charged
• Never mix normal batteries with rechargeable batteries. Either use 2 batteries or 2 recharge-
• For the proper disposal of (rechargeable) batteries, please read the chapter "Disposal".
Preparations for Installation
• Keep a minimum distance of at least 1 m to lights, radiators and other heat sources in order
• Only install the motion detector on a stable surface.
• The motion detector can be mounted on a wall in indoor and outdoor areas. Pay attention to
Function of the motion detector
The motion detector responds to temperature changes within the detection range, e.g. if a
person, an animal or a car with a different temperature to the detection area enters the detec-
tion area.
To ensure optimal motion detection, the motion detector must be placed so that the object to
be detected does not approach the motion detector directly but passes from left to right or vice
versa. Mind this, when installing the product.
The transmission range for the detection of a motion is determined by several factors:
• Mounting height of the motion detector
• Temperature difference between the moving object and the background (environment)
• Size of the object
• Distance of the object from the motion detector
• Direction and speed of the movement
• Ambient temperature
Installation
The wall bracket can be fastened to the wall using 2 screws. Use, depending on the mounting
location, appropriate screws and if necessary dowels.
Pay attention when drilling and tightening the screws that no cable or pipes are damaged.
The motion detector is slided from above onto the wall bracket. By means of the wall bracket's
fl exible head the motion detector can be aligned to the required detection range.
Getting Started
• Open the motion detector by unscrewing the four screws on the back of the device.
• When the battery compartment is at the top, you will fi nd the sliding switch for the channel
☞
• With the lower sliding switch you can adjust how long the load shall be switched on when the
dren or pets. If swallowed, consult a doctor immediately.
acid burns, therefore, use suitable protective gloves.
There is a risk of explosion!
chargeable batteries that are intended for this purpose; use a suitable battery charger.
batteries. If batteries/rechargeable batteries are too old, they may leak and cause damage to
the product, which will lead to the loss of the warranty/guarantee!
attention to plus and minus).
batteries with ones that are half full.
able batteries.
Please refer to the "Safety Information" section!
to avoid functional problems or faulty switching.
the correct mounting position. The side that is shaped like a cover must always face upwards,
otherwise water might enter the product.
selection on the left. Thereby please note that you move the sliding switch to the "LEARNING"
position.
The other three switch positions "IV-1", "IV-2" and "IV-3" are intended for an other ra-
dio switching system by the manufacturer and must not be used for the RSL system.
motion detector is triggered.
You can set a time period of 5 minutes, 1 minute, 15 seconds and 6 seconds.
