PARTS LIST
RCLP50V
KEY
NO.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
103856
All manuals and user guides at all-guides.com
This list contains replaceable parts used in your heater. When ordering parts, follow the
instructions listed under Replacement Parts on page 9 of this manual.
PART
NO.
DESCRIPTION
099568-01
Inner Shell (Combustion Chamber)
M11084-26
Hex Tap Screw, #10-16 x 3/8"
099599-01AC
Outer Shell (RCLP50V)
M51104-01
Handle
099230-01
Hex Tap Shoulder Screw
M11084-29
Hex Tap Screw, #10-16 x 3/4"
M11084-27
Hex Tap Screw, #12-14 x 1/2"
099393-03
Knob, Control
103931-01
Burner Assembly
099539-01
Electrode Ignitor
M11084-38
Hex Tap Screw, #8-18 x 3/8"
099537-03
Fan
103864-01
Motor Assembly (Includes Rubber Washer
and Fan Nut)
099540-01
Fan Guard
097384-02
Captive Washer Nut
097968-05
Hex Screw, #4-40 x 1/2"
NPC-00C
Hex Nut, #4-40
101481-05
Thermal Switch Kit
097776-01
Universal Bushing
099202-02
Steel Rivet, 1/8"
103919-01
Thermocouple Kit
103921-01
Valve/Orifice Assembly
102445-01
Piezo Ignitor
078978-03
Sleeve Cap
103922-01
Base Assembly
100397-01
Lock Washer, #4
PARTS AVAILABLE - NOT SHOWN
097941-25
Tradename Decal (RCLP50V)
103867-02
General Information Decal
103869-02
Operation Decal
079663-01
LP Warning Decal (English)
079663-02
LP Warning Decal (French)
099672-02
Notice Decal
ACCESSORIES
LPA3055
Regulator & Hose Assembly
LPA1020
3 m (10 ft) Hose
LPA2140
Regulator
LPA4020
Fuel Gas Connector
OWNER'S MANUAL
11
QTY.
1
7
1
1
4
2
3
1
1
1
1
1
1
1
3
2
2
1
1
1
1
1
1
1
1
4
2
1
1
1
1
1
1
1
1
1
