  • Page 1 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:25 PM Page 1 MultiSync MultiSync ® ® IntelliBase IntelliBase ™ ™ Audio Audio User’s Manual User’s Manual...
  • Page 2 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:25 PM Page 2 Index Contents Quick Start 2 –11 Controls Specifications Troubleshooting References Limited Warranty Table des matières Contenu Démarrage rapide 2 0 –29 Commandes Caractéristiques Dépannage Références...
  • Page 3 Servicing — The user should not attempt to service the appliance. Servicing should be referred to qualified service personnel or returned to the dealer or call the NEC TECH service line for assistance at 1-800-632-4662. The FCC Wants You to Know 1.
  • Page 4 Plate A Adapter Screws Plate B Registration Card MultiSync IntelliBase Audio * Remember to save your original box and packaging material to transport or ship the MultiSync IntelliBase Audio. Note: You can register your product on the Internet at http://www.prodreg.com/nec...
  • Page 5 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:25 PM Page 5 Quick Start How to attach IntelliBase ™ Audio to your MultiSync ® brand monitor MAKE SURE THE MONITOR IS DISCONNECTED FROM THE SYSTEM AND IS UNPLUGGED FROM THE WALL OUTLET BEFORE ANY WORK IS DONE ON THE MONITOR.
  • Page 6 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:26 PM Page 6 MultiSync Monitor Model Names MultiSync 50, MultiSync 70, XV15 and XV15+ Step 1 With the monitor MONITOR IN POSITION TO REMOVE THE BASE AND ATTACH...
  • Page 7 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:26 PM Page 7 Step 3 Locate Adapter Figure 2B Plate “A” that is supplied with ADAPTER PLATE (A) the IntelliBase GUIDE SPINDLE and secure it to THROUGH CENTER...
  • Page 8 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:26 PM Page 8 MultiSync Monitor Model Names MultiSync 90, XE15, XE17, XP15, XP17, XV17, XV17+, A500, A500+ A700, A700+, A900, E500, E700, E900, E900+, M500, M700 and P750...
  • Page 9 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:26 PM Page 9 Step 3 Using a Phillips ORIGINAL MOUNTING screwdriver, remove Figure 3B the screw securing RETAIN the two base halves THESE PARTS TO together as shown USE IN in Figure 3B.
  • Page 10 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:26 PM Page 10 Step 6 Locate the two Figure 3E screws that are supplied with the INTELLIBASE ROTATE ADAPTER (BOTTOM VIEW) IntelliBase PLATE UNTIL IT ALIGNS WITH and attach...
  • Page 11 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:26 PM Page 11 Step 2 Using a Phillips screwdriver, remove the three screws securing the original base to the monitor. Remove the base by sliding and lifting as shown in Figure 4A. Save these screws for use in Step 5.
  • Page 12 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:26 PM Page 12 Step 5 After the adapter plate has been attached to the base, snap the base Figure 4D assembly to the monitor. To accomplish this, position...
  • Page 13 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:26 PM Page 13 Step 8 Locate the two Figure 4G screws that are supplied with the IntelliBase INTELLIBASE ROTATE ADAPTER (BOTTOM VIEW) and attach the PLATE UNTIL IT...
  • Page 14 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:27 PM Page 14 Step 2 Connect one end of the supplied audio cable to the audio input jack on the rear of the IntelliBase (Detail B) and the other end to the audio (line) output jack of your computer system (Detail A) as shown in Figure 6.
  • Page 15 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:27 PM Page 15 Controls POWER: Press the power button to turn the IntelliBase ™ on or off. An indicator light above the button will glow to show power is on.
  • Page 16 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:27 PM Page 16 Specifications Speakers One 75 mm / 3 inch woofer Four 28 mm / 1.1 inch full range Power (Satellites) 4 + 4 Watts @ 4 Ohms with 10% THD...
  • Page 17 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:27 PM Page 17 Troubleshooting SYMPTOMS POSSIBLE PROBLEM SOLUTION NOTE No Sound No power to unit. Make sure all connecting plugs Provided power has been From between the IntelliBase and...
  • Page 18 Page 18 References • BBS (978) 742-8706 NEC Technologies Remote Bulletin Board System is an electronic service accessible with your system and a modem. Communication parameters are: 300/1200/2400/9600/14.4k/28.8k bps, no parity, 8-data bits, 1 stop bit • Customer Service Technical Support...
  • Page 19 Page 19 Limited Warranty NEC Technologies, Inc. (hereinafter “NECTECH”), warrants this Product to be free from defects in material and workmanship and, subject to the conditions set forth below, agrees to repair or replace (at NECTECH’s sole option) any part of the enclosed unit which proves defective for a period of three (3) years from the date of first consumer purchase.
  • Page 20 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:27 PM Page 20 Notes...
  • Page 21 Service — L’utilisateur ne doit pas tenter de réparer l’appareil. Toutes les interventions de service doivent être confiées au personnel de service qualifié. On peut également renvoyer l’appareil au vendeur ou appeler la ligne de service NEC TECH pour assistance au 1-800-632-4662.
  • Page 22 Plaque adaptatrice B Carte d’enregistrement MultiSync IntelliBase Audio * N’oubliez pas de conserver votre carton et votre matériel d’emballage d’origine pour transporter ou expédier le produit MultiSync IntelliBase Audio. Remarque : Vous pouvez enregistrer votre produit sur l’Internet à http://www.prodreg.com/nec...
  • Page 23 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:27 PM Page 23 Démarrage rapide Mode de fixation du système IntelliBase Audio à votre moniteur de marque MultiSync ® S’ASSURER QUE LE MONITEUR EST DÉBRANCHÉ DU SYSTÈME ET DÉBRANCHÉ DE LA PRISE DE COURANT AVANT D’EFFECTUER QUELQUE TRAVAIL QUE CE SOIT SUR LE MONITEUR.
  • Page 24 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:27 PM Page 24 Noms des modèles de moniteurs MultiSync MultiSync 50, MultiSync 70, XV15 et XV15+ Étape 1 Le moniteur étant MONITEUR EN POSITION débranché du système POUR RETIRER LA BASE ET FIXER L’INTELLIBASE...
  • Page 25 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:27 PM Page 25 Étape 3 Repérer la plaque Figure 2B adaptatrice « A » fournie avec PLAQUE ADAPTATRICE (A) l’IntelliBase, et la GUIDER L’AXE À TRAVERS LE fixer à l’axe à...
  • Page 26 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:27 PM Page 26 Noms des modèles de moniteurs MultiSync MultiSync 90, XE15, XE17, XP15, XP17, XV17, XV17+, A500, A500+ A700, A700+, A900, E500, E700, E900, E900+, M500, M700 et P750 MONITEUR EN POSITION Étape 1...
  • Page 27 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:27 PM Page 27 Étape 3 À l’aide d’un MONTAGE D’ORIGINE tournevis à Figure 3B empreinte CONSERVER cruciforme, retirer CES PIÈCES POUR la vis retenant les UTILISATION deux moitiés de base...
  • Page 28 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:27 PM Page 28 Étape 6 Repérer les Figure 3E deux vis qui sont fournies avec INTELLIBASE FAIRE TOURNER LA (VUE DEPUIS PLAQUE ADAPTATRICE l’IntelliBase, LE BAS) JUSQU’À CE QU’ELLE et fixer SOIT ALIGNÉE À...
  • Page 29 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:28 PM Page 29 Étape 2 À l’aide d’un tournevis à empreinte cruciforme, retirer les trois vis retenant la base d’origine au moniteur. Retirer la base en la faisant glisser et en la soulevant comme illustré...
  • Page 30 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:28 PM Page 30 Étape 5 Une fois la plaque adaptatrice fixée à la base, enclencher Figure 4D l’ensemble de base au moniteur. À cette fin, positionner toutes les pattes de blocage sur la base de manière...
  • Page 31 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:28 PM Page 31 Étape 8 Repérer les Figure 4G deux vis qui sont fournies avec FAIRE TOURNER LA INTELLIBASE PLAQUE ADAPTATRICE (VUE DEPUIS l’IntelliBase, JUSQU’À CE QU’ELLE LE BAS) et fixer SOIT ALIGNÉE...
  • Page 32 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:28 PM Page 32 Étape 2 Brancher une extrémité du câble audio fourni à la prise d’entrée audio située à l’arrière de l’IntelliBase (Détail B) et l’autre extrémité à la prise de sortie audio (ligne) de votre système informatique (Détail A) comme illustré...
  • Page 33 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:28 PM Page 33 Commandes POWER : Appuyer sur le bouton POWER pour mettre l’IntelliBasemc en marche ou à l’arrêt. Un témoin lumineux au-dessus du bouton s’allumera pour montrer que l’appareil est sous tension.
  • Page 34 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:28 PM Page 34 Caractéristiques Haut-parleurs Un haut-parleur pour basses fréquences (woofer) 75 mm / 3 pouces Quatre haut-parleurs gamme complète 28 mm / 1,1 pouce Puissance (satellites) 4 + 4 watts à 4 Ohms avec THD 10 % Puissance (caisson de basses) 5 watts à...
  • Page 35 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:28 PM Page 35 Dépannage SYMPTÔME PROBLÈME POSSIBLE SOLUTION REMARQUE Pas de son L’appareil n’est pas S’assurer que toutes les prises de Après s’être assuré dans les branché. connexion entre l’IntelliBase et l’alimentation en courant, il est...
  • Page 36 • BBS (978) 742-8706 Le NEC Technologies Remote Bulletin Board System est un service électronique accessible par l’intermédiaire de votre système et d’un modem. Les paramètres de communication sont les suivants : 300/1200/2400/9600/14,4 k/28,8 k bps, aucune parité, 8 bits de données, 1 bit stop •...
  • Page 37 Page 37 Garantie limitée NEC Technologies, Inc. (ci-après « NECTECH ») garantit que ce produit est exempt de vices de matériaux et d’exécution et, sous réserve des conditions énoncées ci-après, convient de réparer ou de remplacer (au choix exclusif de NECTECH) toute pièce de l’appareil qui s’avère défectueuse pendant une période de trois (3) ans depuis la date d’achat par le consommateur d’origine.
  • Page 38 All manuals and user guides at all-guides.com NEC-ADA201 Eng/Fr. manual 9/8/98 12:28 PM Page 38 Notes...
  • Page 39 Imprimé en Chine MultiSync est une marque déposée de NEC Technologies, Inc. aux É.U. et de NEC Home Electronics Ltd. au Canada, au R.U., en Allemagne, en France, en Espagne, en Italie, en Autriche, au Bénélux, en Suisse, au Danemark, en Finlande, en Norvège et en Arabie saoudite. IntelliBase et Fastfacts sont des marques de commerce de NEC Technologies, Inc.
  • Page 40 Printed in China MultiSync is a registered trademark of NEC Technologies, Inc. in the U.S. and of NEC Home Electronics Ltd. In Canada, UK, Germany, France, Spain, Italy, Austria, Benelux, Switzerland, Denmark, Finland, Norway and Saudi Arabia. IntelliBase and Fastfacts are trademarks of NEC Technologies, Inc.
