Caliber RMD 212 Guide De Démarrage Rapide page 2

7 21
1
8
10
11
9
20
12 2 3
Key System
Short press
1 Power/ACC logic
2 Rotary Volume
3
4
5
6
7 Mode
8 Mute
9
10
11
12
13
14
15
16
17
18
19
20
21
Description of the functions
Panel Release Push this button to release the frontpanel.
Power Power function to activate or deactivate the unit.
ACC Logic After shutdown by turning OFF the ignition, push the power button once and to start the '1 hour play mode' (auto. OFF after 1 hour).
Band Band selection allows you to select different reception bands, f.i. FM1, FM2, FM3 and AM1, AM2
TA TA stands for Traffic announcement which means that it will give you information about the traffic (if broadcasted) no matter what mode you are in (SD,USB, etc.) it will automatically interrupt the sd/
USB and give the information, after that it automatically switches back to the selected mode
Manual up/down Long press to move the radio frequency number up/down step by step.
Menu (system) Press the VOL/SEL button for several seconds to activate the cyclical mode to choose from the following user instructions: AF ON/OFF >TA SEEK/ALARM > PI SOUND/MUTE > RETURN S/L >
MASK ALL/DPI (rotate to adjust).
Audio Menu The Audio menu button gives you the possibility to adjust your sound system with the following options Bass, Treble, Balance and Fader. These options can be used to fine tune your sound.
In EQ mode you can choose from preset EQ settings: FLAT, CLASSIC, POP, ROCK
Mode The mode button allows you to go from one source to another source (f.i. Tuner) by pushing the button as many times as needed.
Rotary volume This knob allows you to adjust the volume from minimum to maximum level. NOTE high sound levels may cause damage to your ears.
M1-M6 These are the preset stations where you can store your favorite radio stations if in tuner mode.
Pause/Play This button allows you in USB or SD mode to play or to pause the music.
Scan Scan will play 10 seconds of each song on the USB or SD. If the preferred song is playing, push again and it will play that song.
Repeat Repeat will play a selected song or album continuously. Available in USB and SD mode.
Shuffle Shuffle will play all the songs random. Available in USB and SD mode.
File down/up In MP3 mode press this button to go up or down one folder.
Track down/up In MP3 mode press this button to go up or down one track
fast forward/backward Long press to fast forward to the USB or SD.
3,5mm AV jack in To connect an external audio system.
USB poort When inserting a USB stick the unit will switch to USB mode.
SD card input (behind panel) Remove the frontpanel to insert SD card. When inserting a SD card the unit will switch to SD mode. (Max 32GB card)
Reset (behind panel) Use a non-metallic pointed object to press and hold the reset button for 5 seconds. The unit will be set to factory default.
All manuals and user guides at all-guides.com
5
14 15 16 17
long press Short press
Power off
Menu (audio / system)
Mode
Band
Seek down
Seek up
Scan
M1
M2
M3
M4
M5
M6
PTY
TA
4
6
18 19 13
Tuner
long press
Panel release
LCD display
USB port
Manual down
Manual up
3,5mm AUX In Jack
Store M1
Store M2
Store M3
Store M4
Store M5
Store M6
MP3/WMA
Short press long press
Enter
Mode
Track down fast backward
Track up fast forward
Play/Pause
Intro
Repeat
Shuffle
Folder down
Folder up
