PLUG IN READY OPERATION
INSTALLATION INSTRUCTION - STEP 1
Plug And play Ready Operation
To prepare the hand dryer for 'plug and play' ready operation, proceed as follows:
1. Remove the hand dryer cover.
2. Run the supplied power cable though the back power supply hole.
3. Attach the negative cable to the negative terminal (labeled N).
4. Attach the postive cable to the postive ground terminal (labeled L).
5. Proceed to the second step of installation.
Hard Wire Operation
You have the option of utilizing the supplied power cord, or by utilizing you own wires. To utilize the supplied power cord,
proceed as per the instructions 'Plug and Play Ready Operation'. To utilize your own wires.
1. Feed wires though the power supply hole (14 AWG or better); tighten clamp down on wire.
2. Connect the wires to the slots on the terminal marked N and L
All manuals and user guides at all-guides.com
The Royal Sovereign hand dryer provides maximum flexibility when
installing the hand dryer. The hand dryer is plug and play ready.
Simply connect 2 wires to the terminal slots - Positive (L) and
Negative (N). A hard-wire option is also available, for those who do
not want to use the supplied power supply. Simply use your own power
cable (14 AWG or better)
8
