R C 8 3 2
CONFIGURATION ANDFUNCTIONS :
1. SleepButton
2. Tuning Down/Hour Button
3. Tuning Up/Minute Button
4. Preset/Memory Up/
Time Set Button
5. Built-In Speaker
6. AM/FM Button
7. Volume Down/AlarmButton
8. Volume Up Button
9. On/Standby/AlarmOff Button
10. SnoozeButton
11. Alarm Indicator -
Buzzer / Radio
12. LED Display
13. Battery Compartment
(Bottom side -
Backupbatteries)
14. Sleep Indicator
CONNECTING THE UNIT
Insert the wired plug correctly into a power outlet. The clock display will show "00 : 0 0" and you
need to set the correct time. It will also return to show "00 : 0 0" if there has been a power out and
no back-up battery is fitted.
TO SET THE TIME
Set the unit to Standby mode. You can only set the time when unit is in Standby mode.
1. Press and hold the Time Set Button for about 2 seconds. Then the current time will be
flashing. Release the button.
2. Press the Hour Button once and repeatly to adjust the hour digit.
3. Press the Minute Button once and repeatly to adjust the minute digit.
Note: Press and hold the Hour/Minute Button will change the digit at a fast speed.
4. Press once again the Time Set Button when it reaches the right time. Then the
current time will stop flashing.
RADIO OPERATION
1. Press the On/Standby Button to set the unit to Radio mode.
2. Select the AM or FM band by pressing the AM/FM Button. Then the AM or FM
frequency will show on the LED display.
3. Tune a station by pressing the Tuning Up/Down Button.
Pressing either Tuning Up/Down Button for more than 1 second to activate the automatic
tuning mode. The automatic tuner will scan up or down and lock onto the next station. If the
automatic tuning does not precisely tune into a radio station, press the Tuning Up/Down
Button to adjust the tuning.
4. Adjust the volume by pressing Volume Up/Down Button.
5. To turn off the radio, press the On/Standby Button to set the unit to Standby mode.
6. After tuned into a radio station, the unit will return to show the current time instead of
the radio frequency after a few seconds.
7. If you want to check the radio frequency, press either once the Tuning Up or Tuning Down
button then the unit will show the radio frequency for a few seconds.
STORES PRESET STATIONS
Up to 10 stations (10 AM and 10 FM) can be stored in memory :
1. Under RADIO mode, select the waveband by pressing the AM/FM Button.
2. Tune to a desired station as described in previous section.
3. Press and hold the Preset/Memory Up Button for about 2 seconds then the Preset Station
Number will flash. Release the button.
4. Press once or more times the Volume Up/Down Button to select your desired Preset
Station Number from P1 to P10.
5. Press once the Preset/Memory Up Button then the Preset Station Number will stop flashing.
Now the station is stored in your desired Preset Station Number.
To replace a station stored in the memory, repeat all the stages described above. The new
station will replace the previously stored one.
To receive Preset Stations :
1. Under RADIO mode, select the waveband by pressing the AM/FM Button.
2. Press once or more times the Preset/Memory Up Button to select the desired Preset
Station Number.
TO SET THE ALARM TIME AND THE ALARM MODE
Set the unit to Standby mode. You can only set the alarm time when unit is in Standby mode.
1. Press and hold the the Alarm Button for 2 seconds Then the alarm time will be flashing.
Releasethebutton.
2. Press the Hour Button once and repeatly to adjust the hour digit.
3. Press the Minute Button once and repeatly to adjust the minute digit.
Note: Press and hold the Hour/Minute Button will change the digit at a fast speed.
4. Press once again the Alarm Button when it reaches the right time. Then the alarm time
will stop flashing. The alarm time is set.
5. Press once or more times the Alarm button to select which type of alarm you like as below
:-
a) Alarm - Indicator light on : Buzzer selected as alarm type.
b) Alarm - Indicator light on : Radio selected as alarm type.
c) Alarm -
& Indicators both light off : No alarm selected, meaning
that the unit will not alarm when it reaches the Alarm set time.
All manuals and user guides at all-guides.com
A M / F M A L A R M C L O C K
5
1 7 8 4 6 2 3 9
11 12 10 13 14
USE THE ALARM
1. Set the Alarm time and select alarm type as described in previous section. Make sure the
Alarm indicator is on.
2. W hen it reach the alarm time, you can hear the radio or buzzer sound depending on
which alarm type you have selected before.
3. Press once the Alarm Off Button to turn off the alarm sound then the radio or buzzer
sound will be off.
Note : If you selectAM or FM Radio as alarm type, make sure you have turned a desired
station and a suitable volume level before using this alarm type.
SNOOZE OPERATION
To obtain approximatively further 9 minutes sleep, press the Snooze Button after the radio or the
buzzer switch on at the preset wake-up time. The Alarm Indicator will be flashing. This will
silence the radio or the buzzer for 9 minutes. You can repeat this operation for up to about 1
hour.
GOING TO SLEEP WITH THE SOUND OF THE RADIO
1. Press once the Sleep Button to activate the Sleep function. The Sleep Indicator will on.
2. Press once and repeatly the Sleep Button to select the sleeping time (minutes) as
90-80-70-60-50-40-30-20-10 -OFF (OFF meaning that Sleep function is cancelled).
After setting the sleeping time, the radio will on and off and return to standby mode when it
reached the sleep set time.
If you want to cancel the sleep funciton, simply press once the On/Standby Button then the
sleep function will be disable. The Sleep Indicator will off and the unit will return to Standby
mode.
GOING TO SLEEP AND WAKENING TO THE SOUND OF THE UNIT
1. Repeat steps described in "TO SET THE ALARM TIME AND THE ALARM MODE"
and "USE THE ALARM".
2. Press the Sleep Button and set the period of time you want to listen to the radio
before it switches off automatically.
3. The radio is now programmed to turn itself off after you go to sleep and the alarm will
on automatically at the preset wake-up time.
BATTERY BACK-UP
This clock radio has a back-up power system to ensure continuous operation of the clock in the
event of a power failure. The switch from AC to battery power is automatic. However, under
battery power, the clock display will not illuminate even though the clock maintains the correct
time and stores the alarm time in the memory. The system operates on 2x1.5V "AAA" size
batteries (not included). We recommend the use of a long life battery to ensure maximum
performance.
CHECKING THE TIME DURING NO SUPPLY OF AC POWER (WITH BACKUP
BATTERIES)
W hen there is no supply of AC power but the unit is fitted with 2x1.5V "AAA" size batteries (for
backup), the display will not show any information. However, you can still check the current time
by pressing any button and the current tme will be displaying for a few seconds. But, It will not
alarm when it reaches the preset alarm time.
ANTENNA
The unit has a flexible wire on the back of the unit and it should be extended to its full length for
best reception white receiving FM radio. For AM, the radio is supplied with a built-in directional
aerial, rotate the unit for the best AM reception.
SPECIFICATIONS
Power Source : AC230V ~ 50Hz
DC3V
back-up) (battery not included)
Frequency Range : FM 87.5-108 MHz
AM 522-1620 kHz
Dimensions : 150(L) x 98(D) x 70(H) MM
Weight : 310g
Weight and dimensions are approximate because we continually strive to improve our products,
specifications may change without prior notice.
WARRANTY
1. This unit is guaranteed for a period of 24 months from the date of
production printed on the product itself or on label on product.
2. The warranty is valid only if the unit has not been tampered with. The
warranty is valid only at authorized TREVI assistance centres, that
will repair manufacturing defects, excluded replacement of labels and
removable parts.
3. TREVI is not liable for damage to people or things caused by the use of
this unit or by the interruption in the use of this unit.
E N G L I S H
, 2x1.5V "AAA" size batteries type (for clock
