Storage Credenza
Adept Storage Collection | 417653
Need help? Visit Sauder.com to view video assembly tips or chat with a live rep.
Prefer the phone? Call 1-800-523-3987.
Share your journey!
You'll love what we
have in storage.
NOTE: THIS INSTRUCTION
BOOKLET CONTAINS IMPORTANT
SAFETY INFORMATION.
PLEASE READ AND KEEP FOR
FUTURE REFERENCE.
English pg 1-18
Français pg 19-21
Español pg 22-24
Lot # 386735
11/13/15
Purchased: __________________
Be sure to give us a ring before
making any returns. 1-800-523-3987

Publicité

loading

Manuels Connexes pour Sauder Storage Credenza 417653

Sommaire des Matières pour Sauder Storage Credenza 417653

  • Page 1 Adept Storage Collection | 417653 NOTE: THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY INFORMATION. Need help? Visit Sauder.com to view video assembly tips or chat with a live rep. PLEASE READ AND KEEP FOR FUTURE REFERENCE. Prefer the phone? Call 1-800-523-3987.
  • Page 2 • Check the size and weight of your TV. Compare it to the diagram below – before you begin assembly! • This Sauder unit is designed for use with televisions weighing less than 50 pounds. Never use with a TV that weighs more.

  • Page 3: Part Identifi Cation

    END (2) SHELF (1) BOTTOM MOLDING (1) UPRIGHT (2) BACK (1) SHELF MOLDING (1) SMALL UPRIGHT (2) ADJUSTABLE SHELF (3) END MOLDING (2) TOP (1) LEFT FRONT/RIGHT REAR LEG (2) BOTTOM (1) RIGHT FRONT/LEFT REAR LEG (2) www.sauder.com/services 417653 Page 3...
  • Page 4 RUBBER SLEEVE - 12 HOLE PLUG - 2 METAL PIN - 12 BLACK 9/16" LARGE HEAD SCREW - 16 BLACK 1-7/8" FLAT HEAD SCREW - 8 BLACK 9/16" FLAT HEAD SCREW - 4 SILVER 1/2" MACHINE SCREW - 6 Page 4 417653 www.sauder.com/services...
  • Page 5 Look for this icon. It means a Step 1 video assembly tip is available at www.sauder.com/services/tips Assemble your unit on a carpeted fl oor or on the empty å carton to avoid scratching your unit or the fl oor. Do not tighten the HIDDEN CAMS in this step.
  • Page 6 Step 2 Turn sixteen CAM SCREWS (8F) into the LEGS (I and J) å and SHELF MOLDING (L). (16 used) Page 6 417653 www.sauder.com/services...
  • Page 7 (and snacks) required. å six HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS insert into å the ENDS (A). These surfaces must be even. The LEG should overhang this edge. The LEG should overhang this edge. www.sauder.com/services 417653 Page 7...
  • Page 8 Shoulder These edges should be even. Apply pressure with your hands as you guide the MOLDINGS over BLACK 9/16" FLAT HEAD SCREW the SCREWS and onto the ENDS. (4 used in this step) Page 8 417653 www.sauder.com/services...
  • Page 9 LEGS (I and J). Fasten the remaining LEGS (I and J) to the ENDS (A). å Tighten six HIDDEN CAMS. NOTE: Be sure the WOOD DOWELS insert into å the ENDS (A). These surfaces must be even. www.sauder.com/services 417653 Page 9...
  • Page 10 Tighten Risk of damage or Arrow injury. HIDDEN CAMS must be completely Arrow Maximum tightened. HIDDEN 210 degrees CAMS that are not completely tightened may loosen, and parts may separate. To Minimum completely tighten: 190 degrees Page 10 417653 www.sauder.com/services...
  • Page 11 BLACK 1-7/8" FLAT HEAD SCREWS (2S). Minimum 190 degrees These holes must be here. S u r f a c H I D D E N i t h BLACK 1-7/8" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 417653 Page 11...
  • Page 12 I D D u t H i t h o f a c S u r D E N H I D i t h f a c S u r Maximum Arrow 210 degrees Minimum 190 degrees Page 12 417653 www.sauder.com/services...
  • Page 13 BLACK 1-7/8" FLAT HEAD SCREWS (2S). Minimum 190 degrees These holes must be here. S u r f a c H I D D E N i t h BLACK 1-7/8" FLAT HEAD SCREW (4 used in this step) www.sauder.com/services 417653 Page 13...
  • Page 14 (6 used for the CARD HOLDERS) The open slots on the card holders must be facing up. These edges are almost even. l e s Maximum w i t Arrow 210 degrees r f a Minimum 190 degrees Page 14 417653 www.sauder.com/services...
  • Page 15 Fasten the BOTTOM MOLDING (K) to the å BRACKETS on the BOTTOM (E). Use four BLACK 9/16" LARGE HEAD SCREWS (1S). BLACK 9/16" LARGE HEAD SCREW These edges must be even. (8 used in this step) www.sauder.com/services 417653 Page 15...
  • Page 16 Do not stand the unit upright without the BACK fastened. The unit may collapse. These holes must line up over the SHELF and UPRIGHTS. NAIL (64 used in this step) BLACK 9/16" LARGE HEAD SCREW (8 used for the FEET) Page 16 417653 www.sauder.com/services...
  • Page 17 IMPORTANT: The ADJUSTABLE FEET should not extend å beyond the bottom edges of the LEGS (I and J). With your No. 2 Phillips Screwdriver, turn the ADJUSTABLE FEET downward until they touch the fl oor. Floor www.sauder.com/services 417653 Page 17...
  • Page 18 Refer to instruction book for complete safety information. Note: This is a permanent label. Do not try to remove. Surface will be damaged. 50 lbs. 30 lbs. total 25 lbs. 25 lbs. 25 lbs. 50 lbs. total (12 used) Page 18 417653 www.sauder.com/services...

  • Page 19: Crédence De Rangement

    QUANTITÉ d’ a chat de cet élément et conserver le livret pour future référence. EXTRÉMITÉ ..............2 34E PIED RÉGLABLE ............2 Pour contacter Sauder MONTANT.................2 EXCENTRIQUE ESCAMOTABLE ....36 en ce qui concerne cet PETIT MONTANT ............2 CHEVILLE D'EXCENTRIQUE ......20 élément, faire référence au numéro de lot et...
  • Page 20 Aligner la rainure des MOULURES sur les têtes des VIS dans diagramme ci-dessous avant de commencer l'assemblage ! les EXTRÉMITÉS. • Cette unité Sauder est conçue pour les téléviseurs pesant moins de 22 kg. Ne jamais utiliser avec des téléviseurs plus lourds. ÉTAPE 5 •...
  • Page 21 TABLETTE et les MONTANTS. Fixer le PIED RÉGLABLE (34E) au DESSOUS (E). Utiliser huit VIS TÊTE LARGE 14 mm NOIRES (1S). REMARQUE : Les réglages des PIEDS RÉGLABLES se feront à l’étape 13 une fois l’unité en position verticale. www.sauder.com/services 417653 Page 21...

  • Page 22: Lista De Partes

    EXTREMO ................2 34E PATA AJUSTABLE ............2 et conserver le livret pour future référence. PARAL ..................2 EXCÉNTRICO ESCONDIDO ......36 Pour contacter Sauder PARAL PEQUEÑO ............2 PASADOR DE EXCÉNTRICO ......20 en ce qui concerne cet PANEL SUPERIOR ............1 BIELA DE EXCÉNTRICO ........16 élément, faire référence...
  • Page 23 • Verifi que el tamaño y peso del televisor. ¡Compárelo al diagrama abajo - antes de comenzar el ensamblaje! PASO 4 • Esta unidad Sauder está diseñada para ser usada con televisores cuyo peso sea inferior a 22 Kg. Nunca la use para un Cuidadosamente vuelva los EXTREMOS (A) al revés.
  • Page 24 Los márgenes a lo largo de los dos bordes largos y cortos del DORSO (G) deben estar uniformes. Empuje sobre las esquinas opuestas de la unidad si es requerido para hacerla "cuadrada." Fije el DORSO (G) a la unidad utilizando los CLAVOS (1N). Page 24 417653 www.sauder.com/services...
  • Page 25 équipé. • Blessure physique. Le mobilier peut être très lourd. • Ne pas pousser le mobilier, surtout sur la moquette. Se faire aider par une autre personne pour soulever l’élément et le mettre en place. www.sauder.com/services 417653 Page 25...
  • Page 26 • Lesión física. El mobiliario puede ser • No empuje la unidad, especialmente muy pesado. sobre un piso alfombrado. Pide la ayuda de otra persona en levantar la unidad y colocarla en lugar. Page 26 417653 www.sauder.com/services...

  • Page 27: Garantie Limitée De 5 Ans

    à compter de la date d'achat la première fois et qui sont signalés à Sauder dans les limites de couverture de la contre tout défaut de matériaux ou de fabrication des composantes de mobilier Sauder.
  • Page 28 Dear Valued Customer: So, how did it go? Thanks so much for choosing Sauder® furniture. I hope the Set a world record for speed? purchase and assembly process was a positive experience Feeling good about yourself? and you feel good about the furniture you just built. If you Nice.
