Before you begin, make sure all parts shown are included with your product.
Parts List
Description
A wall arm assembly
B adapter bracket
C wood screw
D concrete anchor
E portrait lock clip
F fastener caps
G cable ties
H M5 x 13mm self tapping screws
I M5 flat washers
J 5 mm allen wrench
K 6.75" cable cover
L 4.25" cable cover
M #3 screwdriver bit
N 5/32 allen wrench
Parts may appear slightly different than illustrated.
C
D
F
J
N
Qty. Part #
1
095-1828
2
095-1787
4
520-1202
4
590-0320
4
095-1734
590-1324
4
8
590-1168
4
520-1616
4
540-1040
1
560-9640
2
095-1818
2
095-1817
1
560-0209
1
560-9646
E
L
M
3 of 38
G
K
ISSUED: 01-25-12 SHEET #: 095-9368-6 01-07-14
A
B
H
I
