– Impairment of hearing
– Risk of personal injury due flying particles.
– Risk of burns due to accessories becoming hot during
operation.
– Risk of personal injury due to prolonged use.
– Risk of dust from hazardous substances.
LABELS ON TOOL
In addition to the pictographs used in this manual, the labels
on the tool show the following pictographs:
Read instruction manual before use.
Wear safety glasses.
Wear ear protection.
Date Code Position (Fig. B)
The Date Code (13), which also includes the year of
manufacture, is printed into the housing.
Example:
2017 XX XX
Year of Manufacture Package Contents

THE PACKAGE CONTAINS

1 Jigsaw
1 Blade
1 Instruction manual
1 Wrench
1 Warranty card
1 Service center list
• Check for damage to the tool, parts or accessories which
may have occurred during transport.
• Take the time to thoroughly read and understand this
manual prior to operation.
Description (Fig. A to J)
WARNING: Never modify the power tool or any part
of it. Damage or personal injury could result.
1. Trigger switch
2. Lock-on button
3. Speed controller
4. Dust cover
5. Blade clamp actuator
6. Blade clamp
7. Saw blade
8. Pendulum Stroke selector
9. Shoe plate
10. Dust extraction outlet
11. Wrench
12. Screw-blade clamp
13. date code
14. Vacuum nozzle (optional)
15. Screw-shoe plate
(Original instructions)
16. Cutting line
17. Rip fence (optional)
18. Screw (optional)
19. Clamp bar (optional)

ELECTRICAL SAFETY

Only one voltage is applicable to this tool. Be sure to check
that the power supply corresponds to the voltage on the rating
plate.
Your Stanley tool is equipped with double insulation,
hence, it does not require to be earthed
When the power cord is damaged, have it sent to a STANLEY
service center for replacement to specially prepared cables.
USING AN EXTENSION CABLE
If an extension cable is required, use an approved 3–core
extension cable suitable for the power input of this tool (see
Technical Data).The minimum conductor size is 1.5 mm2; the
maximum length is 30 m.
When using a cable reel, always unwind the cable completely.

ASSEMBLY AND ADJUSTMENT

WARNING: To reduce the risk of serious personal
injury, turn tool off and disconnect tool from power
source before making any adjustments or
removing/installing attachments or accessories.
Before reconnecting the tool, depress and release
the trigger switch to ensure that the tool is off. An
accidental start-up can cause injury.
Fitting the saw blade:
(SJ60) (Fig.A-1)
• Lift dust cover (4).
• Hold the saw blade (7) as shown, with the teeth facing
forward.
• Push the blade clamp actuator (5) away from the shoe
plate (9).
• Insert the shank of the saw blade into the blade clamp (6)
as far as it will go.
• Release the blade clamp actuator (5).
• Turn down dust cover (4).
(SJ45) (Fig. A-2)
• Loosen (do not remove) the two screws-blade clamp. (12).
• Hold the saw blade (7) with the teeth facing forward.
• Insert the shank of the saw blade (7) into the blade clamp
(6) as far as it will go.
• Slightly tighten the two screws-blade clamp (12)
alternately to position the blade, then fully tighten the two
screws-blade clamp (12).
WARNING: 1.Always clean out all chips or foreign
matter adhering to blade and/or blade holder.
Failure to do so may cause insufficient tightening of
the blade, resulting in a serious personal injury.
ENGLISH
7
