Piscine Center PLATINIUM 095 Manuel D'utilisation page 79

8.3 Spare part list
Model PLATINIUM 255, PLATINIUM 305
NO Part name
1 Top cover
2
Back panel
3 Back grill
4 Ambient temp. sensor
5
Ambient temp. sensor clip
6 Top frame
7 Evaporator
8 Isolation panel
9
Fan motor bracket
10
Reactor
11 Service panel
12 Wire ring
13 Fan motor
14
Left panel
15
DC motor holder
16 Fan blade
17 Fan panel
18 Front panel
19
Controller box
20
Controller box sponge
21 Rubber ring on water connection
22 Controller
23
Controller box cover
24
Wire connector
25 Right panel
26 High pressure gauge
27 Evaporator support
28
Compressor heating resistor
29
Compressor
30 Sensor holder
31 Evaporator temperature sensor
32
Clip
33
Base tray
34 Evaporator support
35 Evaporator heating resistor
36
Electrical box cover
NO Part name
37 Filter board
38
Driver board
39 PCB
40 Electrical box
41
3-ways terminal block
42 Magnet ring
43 Magnet ring
44
WIFI module
45
2-ways terminal block
46
clip
47 Four-way valve
48 Discharge pipe
49 High pressure switch
50
Discharge temp. sensor
51
4-way valve to evaporator piping
52 Low pressure switch
53 Tube
54 Exchanger to filter
55
EEV
56
Filter
57 EEV to distribution piping
58 4-way valve to exchanger
59
Filter to reservoir
60
Reservoir to EEV
61 Gas return piping
62 Liquid storage tank
63 Water flow switch
64
Rubber ring on water connection
65
Water oulet temp. sensor
66 Exchanger temperature sensor clip
67 Titanium heat exchanger
68
PVC baffle
69
Red rubber ring
70 Water connection sets
71 Water inlet temp. sensor
76
