OVERVIEW
1. Spindle
2. Platter
Place your record here.
3. 45RPM Adaptor
This adaptor allows you to play 45RPM records.
4. Tone arm Lever
The fixed tonearm can be raised and lowered pressing the raise / lower lever.
5. Tone arm Clip
This specially designed arm clip secures the tonearm while at rest or when not in use.
6. Autostop Switch ON/OFF
This switch turns auto stop on or off. When the automatic stop is enabled, the platform will start rotating as soon as the
tone arm is placed over the record and will stop rotating when it has reached the end of the record. Some vinyl records
stop before the end or do not stop when the end is reached. In this case set Auto-stop to OFF.
7. 33 / 45 RPM Switch
This switch controls the RPM of the turntable platter.
Cartridge with needle
8.
When the turntable is not in use, it is recommendable to place the removable protection cover on the stylus.
9. Speaker
Built in stereo speakers.
10. Volume control
Adjust the volume for the internal speakers and headphones.
11. USB port
Use the included USB cable to connect your turntable to your computer. The USB connection will send audio signal
from the turntable to your computer.
12. Line output
The sound signal from long-playing record is sent to this line output. Connect this signal to the line input of an
for example, an amplifier or the line input of a CD/DVD player.
OPERATION
1.
Connect the record player with the power adapter and plug the other end into a wall power outlet.
2. Remove white protective needle cover by gently pulling towards the front of the unit.
3. Place a vinyl record on the turntable platter and select the desired speed (33/45RPM) according
to the record.
4. Open the tone arm clip to release the tone arm. Gently move the tone arm and put the cartridge
onto the desired position of the record and the turntable player starts to play.
5. Turn the volume control knob clockwise to adjust the volume.
Noted: If the AUTO STOP ON/OFF Switch is turned ON, the record will stop automatically when finished. If Auto Stop Control is
turned OFF, record will NOT stop automatically when finished.
