Quickie R-net entry level Notice D'utilisation page 27

8
Supply Voltage:
Operating Voltage:
Peak Voltage:
Reverse Battery Current:
PWM Frequency:
Brake Voltage:
Brake Current:
Charger Connector:
Battery Charging Current:
Maximum Drive Current:
Indicator Outputs:
Lighting Outputs:
Brake Light Output:
Actuator Current:
Moisture Resistance:
Operating Temperature:
Storage Temperature:
EMC tested on sample wheelchair:
Susceptibility:
Emissions:
ESD:
All manuals and user guides at all-guides.com
24 Vdc
16 Vdc to 35 Vdc
35 Vdc
-40 Vdc
12/24 Vdc
1A max.
Use only Neutrik NC3MX
12Arms max.
R-net 80 80A
R-net 90 90A
R-net 120 120A
45W per side
21W per side
42W total
at full speed.
Non LCD Modules -25°C to +50°C
Non LCD Modules -40°C to +65°C
requirements
To EN55022 Class B
