9. Technical diagrams

9.1 Technical diagram

Figure 4
bus
lights right
backrest
legrest right
tilt feedback
9002470 R-net ISM6 actuator & lights
Figure 5
All manuals and user guides at all-guides.com
-
70 A Fuse
bus
lights left
tilt
legrest left
high/low
high/low
feedback
9006378B
ISM
mounting holes
9006378B
