General; Safety; Device Concept; Scope Of Supply - Fronius RC Panel Basic Instructions De Service

General

Safety

Device concept

The remote control can only be used in conjunction with system components of the TPS/i
series.
When using the remote control, the parameters are set and functions selected depending
on the welding process and power source.

Scope of supply

RC Panel Basic,
RC Panel Stand-
ard technical data
All manuals and user guides at all-guides.com
WARNING! Incorrect operation or shoddy workmanship can cause serious injury
or damage. All activities described in this document must only be carried out by
trained and qualified personnel. All functions described in this document must
only be used by trained and qualified personnel. Do not carry out any of the work
or use any of the functions described until you have fully read and understood the
following documents:
- this document
- all the operating instructions for the system components, especially the safe-
ty rules
NOTE! As a result of firmware updates, you may find that your device has certain
functions that are not described in these operating instructions, or vice versa. Cer-
tain illustrations may also differ slightly from the actual controls on your device,
but these controls function in exactly the same way.
Supply voltage
Protection class
Mark of conformity
Dimensions (l x w x h)
(1) Remote control
(2) this document
(1)
(2)
+ 24 V DC
IP 44
CE, CSA
160 x 150 x 70 mm
6.3 x 5.91 x 2.76
19
