• Too long self-closing delay or continuous flushing :
Clean the delay case with a dry cloth, and the calibrated timer
groove with a non metallic point (Fig 5)
• Drip or leak :
Clean the seat washer, and check/clean the seat joint,
or replace it if it is damaged. (Fig 5)
• Water discharge from integrated vacuum-breaker :
Reduce water pressure. Flush tube must not be in full lock on
WC pan and should have a 50° bent.
• Lack/no flushing :
Too low dynamic pressure or insufficient size of pipe.
To remove the mechanism, unscrew the cartridge with a 32mm
A.F. spanner (Fig 1) or 32 mm / 7 mm thick. for recessed valves.
fig. 1
International technical support service : Phone:
+33.3.22.60.22.74 e.mail: sav@delabie.fr
For Douglas Delabie UK market only : Phone: 01491 824449
e.mail: technical@douglasdelabie.co.uk
MAINTENANCE
32 mm
GB
fig. 2
Delay case
Calibrated groove
Lip seal
Piston
Seat washer
