PROGRAM PLAYBACK
1. Place the CD with label side up inside the CD compartment and close the CD door.
2.Press the STOP ( ) button.
3. Press button.
P
4. Select your desired track by / , then press "
5. Repeat step 4 until you have finished programming your selections.
6. Press button to start playback. Open the CD door or turn off the unit, Program will be cancelled.
Note:
CD-up to 20 programs; MP3 up to 99 programs.
LINE IN (AUXILIARY INPUT)
1. Plug one end of cable (not included) into the AUX IN jack of the unit.
2. Plug the other end of the cable into the Headphone or Line Out jack of the external source.
3. Press the button to select Auxiliary mode. The auxiliary icon "AUX" is displayed. Operate your external
SOURCE
auxiliary source as usual.
4. Adjust the volume to desired level.
5. To stop playback, disconnect your auxiliary source from the AUX IN jack.
USB OPERATION
1. Press button to turn on the unit.
SOURCE
2. Connect a USB key with MP3 contents or a MP3 player into the USB port.
3. Press the button to select the USB mode. The USB icon "USB" is displayed.
SOURCE
4. After few seconds, the total no. of folders and tracks will be shown on display, it will start to play automatically.
NOTE:
- The loading time takes about 20s or more depending on the quantity of MP3 files and folders on the disc or USB device.
- The total number of MP3 files on the disc should not exceed 999.
- The maximum number of directories should not exceed 99.
- USB port is not designed for charging function and communication with a computer.
- Manufacturer is not responsible for the playability of USB key or MP3 player due to different recording condition,
capacity, interface compatibility, etc.
MAINTENANCE
Cleaning
WARNING: Disconnect the unit from the mains supply before cleaning.
- Use a soft, dry, clean cloth. Regularly dust the vents at the back or sides.
- Using solvents, abrasive or alcohol-based products risks damaging the appliance.
- If an object or liquid enters inside the appliance, unplug it immediately and have it checked by an authorized engineer.
Notes on disc
* Do not use irregular shape CDs (example: heart-shaped, octagonal ones). It may result in malfunctions.
* Do not place more than one disc in the disc compartment.
* Do not try to open the disc compartment during playing.
* Do not touch the lens. Doing so may cause malfunction.
* If there is a scratch, dirt or fingerprints on the disc, it may cause tracking error. Before playing, clean the disc with a
cleaning cloth. Wipe the disc from the center out. Don't store discs in places with high temperatures or high humidity, they
can become warped. After playing, store the disc in its case.
Important Note
• Before transporting the unit, remove the disc from the disc compartment.
All manuals and user guides at all-guides.com
" button to store your program in memory.
P
EN - 3
SPECIFICATION
POWER SUPPLY: AC: 230V ~ 50Hz
DC9V (UM-2 1.5V x 6)
POWER CONSUMPTION: 14 W
OUTPUT POWER: 2 x 1 WATTS RMS
RADIO
Frequency range
FM: 87.5 - 108 MHz
MW: 522 - 1620 kHz
MORE INFORMATION
CAUTION: To reduce the risk of electric shock, do not remove the cover (or back). There are no user
serviceable parts inside the unit. Refer all servicing to qualify personnel.
The lightening flash with arrowhead symbol within the triangle is a warning sign alerting the user of " dangerous
voltage" inside the unit.
The exclamation point within the triangle is a warning sign alerting the user of important instructions
accompanying the product.
WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
CAUTION: Invisible laser radiation when open and interlocks defeated. Avoid exposure to beam. Class 1 laser product.
CLASS 1 LASER PRODUCT
APPAREIL À LASER DE CLASSE 1
PRODUCTO LASER DE CLASE 1
PRODUTO LASER CLASSE 1
IMPORTANT!
- Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
- Attention should be drawn to the environmental aspects of battery disposal;
- The ventilation should not be impeded by covering the ventilation openings with items such as newspapers, table-cloths,
curtains, etc.
- No naked flame sources, such as lighted candles, should be placed on the apparatus.
- The use of apparatus in moderate climates.
- The apparatus shall not be exposed to dripping or splashing and that no objects filled with liquids, such as vases, shall
be placed on apparatus.
- Ensure a minimum distance of 5cm around the apparatus for sufficient ventilation.
- Do not place objects filled with liquids, such as vases, on the apparatus.
- The marking plate is located on the back of unit.
- Mains plug is used as the disconnect device and it shall remain readily operable. To be completely disconnected the
power input, the mains plug of the apparatus shall be disconnected from the mains completely. The mains plug should
not be obstructed or should be easily accessed during intended use.
- Under the influence of electrical fast transient or/and electrostatic phenomenon, the product may malfunction and
require user to power reset.
- Excessive sound pressure from earphones and headphones can cause hearing loss.
If at any time in the future you should need to dispose of this product please note that Waste electrical products
should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local
Authority or retailer for recycling advice.(Waste Electrical and Electronic Equipment Directive.)
NEW ONE S.A.S
10, Rue de la Mission, 25480 Ecole Valentin, France
