GB PORTABLE RADIO CD PLAyER
GENERAL CONTROLS
1. SPEAKER
2. USB PORT
3. AUX IN JACK
4. AC INPUT SOCKET (~ AC IN)
5. BATTERY COMPARTMENT
6. TELESCOPIC AERIAL
7. BUTTON
SOURCE
8. ( PRESET/ REPEAT/
P
PROGRAM)
POWER SUPPLY
This set operates on AC (230V ~ 50Hz) or DC9V
AC OPERATION:
• Connect the AC Power Cord to your AC household mains outlet and switch on the mains supply. Make sure the voltage
is compatible.
• Disconnect the power cord form the mains when not in use.
USING ON batteries
Open the lid of the battery compartment on the bottom and insert 6 PCS (size C/ UM2) batteries (not supplied), with the +
and – marks correctly aligned, then close the lid. To switch from AC power supply to battery power supply, disconnect the
AC cord from the AC inlet, then disconnect main unit.
The batteries need to be replaced when:
The volume decreases, or sound is distorted during operation.
Notes on batteries
• Do not mix different types of batteries or old batteries with new ones.
• Never recharge the batteries, apply heat to them or take them apart.
• Battery shall not be exposed to excessive heat such as sunshine, fire or the like.
• Attention should be drawn to the environmental aspects of battery disposal.
NOTE: In order to avoid leakage, always remove the batteries when unit will not be used for a long period of time.
AUDIO CONTROLS
Press button to turn on the unit.
SOURCE
During the unit in power on, press to change the different source: FM RADIO, MW RADIO, CD, USB, AUX IN.
SOURCE
All manuals and user guides at all-guides.com
9. : PLAY/PAUSE BUTTON
10. (MEMORY / PAUSE
11. SKIP- / TUNE- BUTTON
12. SKIP+ / TUNE+ BUTTON
13. VOLUME- BUTTON
14. VOLUME + BUTTON
15. CD DOOR
16. CARRYING HANDLE
17. LCD DISPLAY
(UM-2 1.5V x 6)
EN - 1
LISTENING TO THE RADIO
MANUAL SEARCH
1. Press button to select FM or MW band.
SOURCE
2. Select your desired radio station by press the
3. Adjust the volume by
Note: During the manual search in FM operation, double press
station in 100.2, if you advance to 100.3, please press
To enhance radio reception ability:
FM: Extend the FM antenna.
MW: Rotate the unit horizontally for optimum reception.
AUTOMATIC SEARCH
Press and hold the
search operation locates strong stations. A station with a weak signal can be tune manually.
NOTE:
1. During the search operation, the sound level is automatically muted.
2. When the unit in radio mode,LCD displayed AM.(on the packaging, MW will be used instead of AM)
PRESET STATIONS
1. Select a radio station either manually or by automatic search.
2. Press button once, the preset number digits"P01" will blink on the display for few seconds.
3. Press / button to select a preset number.
4. Press again to memorize the radio station in the selected preset number.
5. Repeat steps 1-4 to store other stations.
Note:
When you store a station on a preset number already occupied, the previous station is automatically erased.
)BUTTON
Listening to the preset stations
Press button to select a preset station.
P
LISTENING TO DISC
1. Press button to turn on the unit.
SOURCE
2. Open the CD door.
3. Place the CD with label side up inside the CD compartment and close the CD door.
4. Press the
SOURCE
5. After a few seconds, the total number of tracks and "CD" icon will appear on the display.
TO:
Stop play
Pause play
Resume play after pause
Scan forward and backward
Skip tracks
DISC ERROR
Note: If the disc is dirty, damaged or unreadable, or if the disc is placed upside down, "NO" will appear on the display. If
this occurs, clean the disc, insert the disc correctly or try another disc.
REPEAT PLAYBACK
Press button repeatedly to select among: Repeat 1, REPEAT ALL, REPEAT FOLDER.
P
• " " blinks on LCD - Repeats current track.
• " FOLDER" displayed on LCD – Repeat current folder
• " " displayed on LCD - Repeats entire disc.
• Off - Normal playback.
To cancel REPEAT Playback
Press
P
CD door is opened or turning off the unit.
or .
(volume +) or (volume -) to the desired level.
or
twice.
or button for approx. 2 seconds to start searching in the chosen direction. The automatic
button to select CD function.
once
again
hold /
/
button repeatedly until the repeat indicator disappear. Repeat function is also cancelled when the
EN - 2
will +/- 0.1 step, for example, when the radio
