Relay output in safe area:
Relay functions ............................................ Setpoint, Window, Sensor error,
Hysteresis, in % of span / display range .... 0.1...25 / 1...25
On and Off delay ......................................... 0...3600 s
Sensor error reaction ................................... Break / Make / Hold
Max. voltage ................................................ 250 VAC / 30 VDC
Max. current ................................................ 2 AAC / 2 ADC
Max. AC power ........................................... 500 VA / 60 W
status relay in safe area:
Max. voltage ................................................ 125 VAC / 110 VDC
Max. current ................................................ 0.5 AAC / 0.3 ADC
Max. AC power ........................................... 62.5 VA / 32 W
Marine approval:
Det Norske Veritas, Ships & Offshore ......... Pending
gost R approval:
VNIIFTRI, Cert No. ....................................... Pending
sil certification:
exida, Cert No. ............................................ PREl 070902 P0002 C05
observed authority requirements:
EMC 2004/108/EC ...................................... EN 61326-1
LVD 2006/95/EC .......................................... EN 61010-1
ATEX 94/9/EC .............................................. EN 60079-0, -11, -15 , -26
IECEx ........................................................... IEC 60079-0, -11, -15 and -26
c FM us ....................................................... FM 3600, 3611, 3810
UL, Standard for Safety .............................. UL 61010-1
SIL ............................................................... IEC 61508
of span = of the currently selected measurement range

Configuration of sensor error check

Device:
ERR.ACT=NONE - OUT.ERR=NONE.
9116
Sensor error check:
Configuration
Else:
9116 - Product Version 9116-001
Power and Off
standard:
and EN 61241-0, -11
IEC 61241-0 and -11
CSA E60079-0, -15
CSA 22.2 -25, -142, -213
ANSI/ISA-12.00.01 / 12.12.02
Sensor error detection:
OFF
ON
45
