PR electronics 9116 Mode D'emploi page 44

Input
type
mA
Volt
Pt100, Pt200,
Pt 1000
Pt500, Ni100,
Ni120, Ni 1000
Pt50, Pt400, Ni50
Pt250, Pt300
Pt20
Pt10
TC type:
E, J, K, L, N, T, U
TC type: R, S,
W3, W5, LR
TC type: B
160...400°C
TC type: B
400...1820°C
EMC immunity influence ..................................... < ±0.5% of span
Extended EMC immunity:
NAMUR NE 21, A criterion, burst ....................... < ±1% of span
Auxiliary supplies for 9116B1:
2-wire supply (terminal 54...52) ................... 28...16.5 VDC / 0...20 mA
Auxiliary supplies for 9116B2:
2-wire supply (terminal 54...52) ................... 22...16.5 VDC / 0...20 mA
Wire size (max....min.) ................................. AWG 26...14 / 0.13...2.08 mm
Screw terminal torque ................................. 0.5 Nm
Relative humidity ......................................... < 95% RH (non-cond.)
Dimen., without display front (HxWxD) ....... 109 x 23.5 x 104 mm
Dimensions, with display front (HxWxD) ..... 109 x 23.5 x 116 mm
Protection degree ........................................ IP20
Weight ......................................................... 185 g / 200 g with 4501
42
basic values
Basic
accuracy
≤ ±16 µA
≤ ±20 µV
≤ ±0.2°C
≤ ±0.3°C
≤ ±0.4°C
≤ ±0.6°C
≤ ±0.8°C
≤ ±1.4°C
≤ ±1°C
≤ ±2°C
≤ ±4.5°C
≤ ±2°C
9116 - Product Version 9116-001
Temperature
coefficient
≤ ±1.6 µA / °C
≤ ±2 µV / °C
≤ ±0.02°C / °C
≤ ±0.03°C / °C
≤ ±0.04°C / °C
≤ ±0.06°C / °C
≤ ±0.08°C / °C
≤ ±0.14°C / °C
≤ ±0.1°C / °C
≤ ±0.2°C / °C
≤ ±0.45°C / °C
≤ ±0.2°C / °C
stranded wire
2
