Caliber RCD 110B Guide De Démarrage Rapide page 3

SYSTEM
Key
Short press Long press
1 Mute Power on/off
2 Rotary volume
3
4 Menu
5
6 Display
7
8 Display settings
9
10 Mode
11
12
13
14
15
16
17
18
19
20
21
Panel release
Push to release the front panel.
Power
Power function to activate or deactivate the unit.
Band
Band selection allows you to select different reception bands, f.i. FM1, FM2, FM3, MW.
Mute
Push this button to turn off the sound, push again to return to the last volume level.
AF
AF stands for Alternative frequencies; the tuner will return to alternative frequencies whenever the reception signal is getting worse.
PTY
The PTY function allows you to search for stations with a particular program type like NEWS group and POP group both of these groups are
divided in different subjects. PTY "POP", pop/rock, easy/light, classics/others, jazz/country, nation/oldies. PTY "NEWS", news/info, sport/educatie,
culture/science, weather/finance, social/religion.
Rotary search
Turn to search for the next or previous station automatically or manual.
Menu
Press the button to access the system menu, to adjust the following audio and system Settings:
iXbass, EQ, Bass, Treble, Balance, Fader, Clock, Local, Beep, Area.
Mode
The mode button allows you to go from one source to another source (f.i. Tuner) by pushing the button as many times as needed.
Display settings
In this display menu you can see with PTY setting you are using, and if tou want to display the clock or not.
TA
TA stands for Traffic announcement which means that it will give you information about the traffic (if broadcasted) no matter what mode you are
in (CD, USB, SD) it will automatically interrupt the music and give the information, after that it automatically switches back to the selected mode.
Rotary volume
This knob allows you to adjust the volume from minimum to maximum level. NOTE high sound levels may cause damage to your ears.
M1-M6
These are the preset stations where you can store your favorite radio stations if in tuner mode.
Play/pause
This button allows you in CD, USB or SD mode to play or to pause the music.
INT
INT will play 10 seconds of each song on the USB or SD. If the preferred song is playing, push again and it will play that song.
RDM
Shuffle will play all the songs random. Available in USB and SD mode.
Repeat
Repeat will play a selected song or album continuously. Available in USB and SD mode.
PS
PS stands for Preset stations this means that when you push this button in tuner mode it will automatically switches to the first preset (M1) then it
will go to the next and so on.
AS
AS stands for Autostore; in tuner mode it will automatically store the 6 strongest stations. Note: all previous stored stations are lost
ID3
Hold this button in the MP3 mode to switch the track ID function on or off.
Folder UP/DOWN
In MP3 mode hold this button to go up or down a folder.
3.5mm AUX in jack
To connect an external audio system.
USB slot
When inserting a USB stick the unit will switch to USB mode. (Max 16GB)
CD slot
When inserting a CD the unit will switch to CD mode.
SD card slot
When inserting a SD card the unit will switch to SD mode. (Max 16GB SDHC card)
Reset
(behind panel)
Use a non-metallic pointed object to press and hold the reset button for 5 seconds. The unit will be set to factory default.
TUNER
Short press
Panel release button
Rotary search
3,5 mm. AUX in jack
PS
PTY Band
USB slot
M1
M2
M3
M4
M5
M6
CD slot
SD card slot
Description of the functions
Attention! Never operate the unit while driving
CD/MP3/WMA
Long press Short press
ID3 on/off
AS
Store M1
Play/pause
Store M2
Intro
Store M3
Repate track/all
Store M4
Shuffle
Store M5
Folder UP
Store M6
Folder DOWN
CD eject
Long press
