The measurement values have been
determined in accordance with
ISO 11789:1999.
WARNING!
The actual vibration and noise level when
using tools may differ from the specified
maximum value, depending on how the
tool is used and the material. It is therefore
necessary to determine which safety
precautions are required to protect the user,
based on an estimate of exposure in actual
operating conditions (taking into account all
stages of the work cycle, e.g. the time when
the tool is switched off and when it is idling,
in addition to the start-up time).
DESCRIPTION
Powerful electric edge trimmer with 190 mm
blade and variable cutting depth by lifting
and lowering the support wheel arm. Ideal
for cutting straight edges and limits between
lawns and asphalt, kerbs, drives, paths, and
flowerbeds etc. The use of the product also
prevents grass and weeds from spreading by
cutting off the roots.
1. Power switch handle
2. Front handle
3. Lock knob
4. Bottom tube
5. Motor casing
6. Power switch lock
7. Cord retainer
8. Power switch
9. Lock knob for handle
10. Top tube
11. Blade guard
12. Knob for depth setting
13. Blade
14. Support wheel
15. 2 spanners
16. 2 lock screws for handle
17. Edge guide knob
FIG. 1
ASSEMBLY
WARNING!
Switch off the product and pull out the plug
before assembly and/or adjustment.
FITTING THE FRONT HANDLE
1. Put the front handle on the power switch
handle. Put the screw through the handle
and lock it in place with the lock knob.
FIG. 2
FITTING THE TUBES
1. Align the slot on the bottom tube with the
pin on the motor housing and press in the
tube so that it locks in place.
FIG. 3
NOTE:
Make sure not to damage the cable.
2. Lock in place by tightening the screws.
FIG. 4
3. Put the power switch handle tube on the
top tube, insert the screw through both
tubes from underneath and lock in place
with the lock knob.
FIG. 5
ADJUSTING
Adjusting the trimming depth
There are three settings for the trimming
depth: 16, 25 and 35 mm.
