Human Touch pc 075 Manuel D'utilisation Et D'entretien page 4

get ready
UNPACK THE BOXES
Chair frame
Head frame Head sock
ATTACH THE BODY PAD
1. Slide the body pad onto the chair frame
Slide the body pad onto the lower part of the chair frame,
making sure that the frame slides into the fabric pocket located
on the bottom side of the pad.
2. Secure the body pad
Smooth the body pad into place, from the footrest toward the
backrest. The pad is automatically secured using the hook and
loop fasteners.
humantouch.com
Arm cap (2) Phillips-head
screwdriver
Body pad
Head pad Head pillow
6
Your Human Touch
simple assembly. Just attach the pads, arm caps,
and head pillow, and you're done!
ATTACH THE HEADREST FRAME
1. Raise the chair to an upright position
For your convenience, and to better position the chair for the remaining assembly,
plug in the chair, then use the electric recline lever to adjust the chair to an upright position.
2. Remove the headrest frame screws
Using the Phillips-head screwdriver (provided), remove the two
screws from the headrest frame. Retain them for use in step 4.
3. Insert the headrest frame into the backrest frame
With the arc of the headrest frame pointing toward the back of the chair, slide
the two ends of the headrest frame into the open tube ends at the top of the
backrest frame.
4. Replace the headrest frame screws
Using a Phillips-head screwdriver, replace the two headrest frame
screws, securing the headrest frame to the backrest frame.
7 7
Perfect Chair requires some
® ®
