Menu 04 – Top Display
Unit
The top Right of the Display is used for error messages and useful displays, Error
messages take precedence!
Unit: Displays the TMC-1 Configuration: TMC-1 + XMon, TMC-1+Penta/DAD
TMC-1+D-Mon, TMC-1+A-Mon
LTC: Linear Timecode via GPIO connector
MTC: Midi Timecode via USB connector – if displayed value is incorrect on Pro
Tools change the selected display and then change back.
HUI: HUI position via USB connector. The TMC-1 must be selected as a HUI
Controller on the Workstation
Keyboard: Used to check the keyboard -Hex Display of up to 8 keys
Menu 05 – Hui AFL
This Menu Enables/Disables the HUI AFL function, use if the AFL tally flashes to disable
the AFL function.
Menu 06 – Mute Monitors when Listen Active
No Action
Menu 07 – Cue Output when Talkback Active
Mute Cues
This setting only controls cue sends where Talkback is enabled, Dim Cues attenuates the
cue send by 10 dB.
Menu 08 – Level Display Type
SPL
The Main level display can be shown a SPL, Gain (dB) or Dolby, Gain is absolute but SPL
and Dolby must be calibrated.
2018 CB Electronics
TMC-1 Manuel de référence
Menu 4 - Top Display
LTC MTC
Menu 5 – Hui AFL
Off
Menu 6 –When Listen Active
Menu 7 – Talkback Enable
Dim Cues
Menu 8 – Level Display Type
47
HUI
Mute
dB
Keyboard
Enable
Dim
No Change
Dolby
Version 7
