TMC-1-Penta Only Advanced Menu's

Adv Menu 22 – Set default Analogue Output level (On Menu Exit)
Adv Menu 22 – Analogue Output for 0dBFS
+6dB
The DAD AX32/Penta 720 output cards use relays to set the analogue output level for
0dBFS. If outputs are marked as D2A in the TMC-1-penta application below, then the TMC-
1 will set this in the DAD AX32/Penta 720.
Adv Menu 23 – Alt Output Select
Enable
Speaker selection control
Enable Speaker selection between Main, Alternate and Mini
Disable Speaker selection between Main and Mini only
Adv Menu 24 – Digital Headroom
0dB 2dB
Whenever gain is added there is the possibility of overload, the AX32/Penta 720 have
adequate internal headroom but the inputs and outputs are limited. This setting allows you
to add digital headroom at the output. When no gain is added a SPL setting of 85 is
equivalent to 0dB gain. See Adv menu 16 and 17
Adv Menu 25 – Insert Makeup Gain
Adv Menu 25 – Insert makeup Gain
0dB 2dB
When equalisers are enabled they can have a loss to allow for equaliser gain. This setting
allows you to boost the return signal to keep the levels the same when the equaliser is
enabled. See Adv Menu 15.
2018 CB Electronics
TMC-1 Manuel de référence
+12dB
Adv Menu 23 – Alt Output Select
Disable
Adv Menu 24 – Digital Headroom
4dB
4dB
+18dB
6dB
6dB
55
+24dB
8dB 10dB
8dB 10dB
Version 7
