Channel Plan Editor - Promax RM-010 Manuel

Figure 5.- PROMAX-8 Configuration menu window
The configuration parameters can be stored in files in order to create a library. The
File menu has five options.
New: This option allows a new file to be created in which all the configuration
parameters will be kept.
Open: Allows the contents of a previously saved file to be displayed. The
program shows a list of the configuration files (cfg extension). Click
pointing to the desired file and press the accept button.
Save: This option allows the changes made in the PROMAX-10/8+/8
configuration file to be saved. Configuration files are saved with the cfg
extension.
Save as: This option allows the existing contents of the configuration file to be
saved under a different name from the one it already had. In practice,
this option is used to duplicate the contents of a file and later make
modifications to this that do not affect the contents of the original file.
Exit: This option allows to exit the Configuration menu.

2.3 Channel plan editor

This tool allows to modify the PROMAX-10/8+/8 channel plans. To accede to it
select the Config option in the main menu bar and then click on the Promax-10
Channel Plan option or directly from the main window, click on the Channel plan icon.
Page 8
RM-010 Remote control for PROMAX-10 / 8+ / 8
12/2002
