Datalogger: Permits to open or receive a datalogger acquisition. Datalogger
acquisitions also can be received by clicking on the datalogger icon:
Upgrade: Allows to upgrade the PROMAX-10/8+/8 main software. This option
also can be selected through the upgrade icon:

2.2 Config menu

This menu permits to modify all the configuration parameters of the PROMAX-10/8+/8
and set it as the default configuration. To accede to it select the Config option in the main
menu bar and then click on the Configuration option or well, directly from the main
window, click on the configuration icon. The opened window corresponds to the PROMAX-
10/8+/8 configuration window. This window changes to the PROMAX-10/8+/8 configuration
window when a PROMAX-10/8+/8 configuration is loaded (File - Open) or received
(Receive button). When the program loads a configuration file or communicates with the
unit it detects the unit model and changes the configuration window if needed.
The different parameters of the PROMAX-10/8+/8 configuration window are
grouped into six areas according to the operating mode they affect to:
CH-FR CONFIG:
LOGGER CONFIG:
SCAN CONFIG:
TILT CONFIG:
Page 6
RM-010 Remote control for PROMAX-10 / 8+ / 8
.
Figure 2.- RM-010 main window
Channel-Frequency
parameters.
Datalogger operating mode configuration parameters.
Scan operating mode configuration parameters.
Tilt operating mode configuration parameters.
.
operating mode configuration
