Main power connector
Signal
+3.3 V
+3.3 V
COM
+5 V
COM
+5 V
COM
PWR ON
+5 Vsb
+12 DC
+12 DC
+3.3 V
Color Pin
Orange 1
Orange 2
Black 3
Red 4
Black 5
Red 6
Black 7
Gray 8
Purple 9
Yellow 10
Yellow 11
Orange 12
Pin Color
13 Orange
14 Blue
15 Black
16 Green
17 Black
18 Black
19 Black
20 N/C
21 Red
22 Red
23 Red
24 Black
RF-700WPS2
Signal
+3.3 V
-12 V
COM
PS_ON#
COM
COM
COM
N/C
+5 V
+5 V
+5 V
COM
