repeatedly with a 1 second pause (xx-xx-xx).
2. Radio signal issue: as it is powered on and the ESC
checks the radio signal input. If an issue is detected, the
ESC emits one beep tone repeatedly with a 2 second pause
(x-x-x).

ESC PARAMETERS SETUP

You can adjust several parameters by using the setup button
located on the switch or by using the optional program box
(ORI65153). The green flashing LED indicates the parameter
and the red flashing LED indicates the setting value.
To setup custom parameter settings the optional
program box and PC software are required.
How to modify the parameters settings using the setup
button located on the switch.
A. Power on the ESC.
B. Press and hold the setup button until the green LED starts
flashing and then release the setup button (holding the
setup button for 5 seconds will restore the ESC to factory
defaults).
C. Press the setup button once more.
D. The green LED starts flashing repeatedly, indicating the
currently selected parameter. One flash = parameter 1,
two flashes = parameter 2 and so on. Press the button to
switch between the different available parameters.
E. To change the setting of the actual parameter, press and
hold the setup button until the LED starts flashing red.
F. The red LED flashes indicating the actual setting. One
