Apollo Pluto R Manuel page 15

Line sequence table
Line sequence Color
1 Red（VCC）
2 Blue(K)
3 Black(GND)
4 Green(RX)
5 Yellow(TX)
■
Somewireusethewater-proofconnector,usersarenotabletoseethe
inside color.
Operation Cautions
Be care of the safety use. Don't attempt to release the connector
when battery is on power.
◆ Try to avoidhitting.
◆ Do not modify system parameters to avoid
parametersdisorder.
◆ Make the display repaired when error codeappears.
Attached list 1: Error code definition
Function
+
Lock
-
RX
TX
Attached list 2：Power assist table
Level
Level
Item
0-3/1-3
0-5/ 1-5
0-7/ 1-7
0-9/ 1-9
Error Code
21
22
23
24
25
30 Communication Abnormality
1 2 3 4 5
50% 74% 92% — —
50% 61% 73% 85% 96% —
40% 50% 60% 70% 80% 90% 96% —
25% 34% 43% 52% 61% 70% 79% 88% 96%
Definition
Current Abnormality
Throttle Abnormality
Motor Abnormality
Motor Hall Abnormality
Brake Abnormality
6 7 8 9
— — — —
— — —
—
15
