2. Installation and Operation

NOTE: Before installation, please inspect the unit. Make sure that nothing inside the package is damaged.
Please keep the original package in a safe place for future use.
NOTE: There are two different types of E4 LCD Pro TM UPS: standard and long-run models. Please refer
to the following table.
Model
E4 LCD Pro TM 10k
E4 LCD Pro TM 15k
E4 LCD Pro TM 20k

2-1. Unpacking and Inspection

Unpack the package and check the package contents. The shipping package contains:

One UPS

One user manual

One monitoring software CD

One RS-232 cable

One USB cable

One battery cable (only available for long-run models)

2-2. Rear Panel View

Diagram 1 : E4 LCD Pro TM
10k Rear Panel
INFOSEC UPS SYSTEM – 15, Rue du Moulin – 44880 Sautron – France – www.infosec-ups.com
35
Hot Line Tel : +33 (0)2 40 76 15 82 – fax : +33(0)2 40 94 29 51 – hotline@infosec.fr – 11 16 AA XX 201 07
Version
E4 LCD Pro TM 10k S
Standard model E4 LCD Pro TM 15k S
E4 LCD Pro TM 20k S
Diagram 2 : E4 LCD Pro TM
15k Rear Panel
Model
Long-run model
Diagram 3 : E4 LCD Pro TM
20k Rear Panel
Version
