These indicators blink green while the LAN ports were transmitting
data.

1.3 The Rear Ports

PORT
POWER Jack(2)
WAN(3)
LAN(4)
Reverse SMA(5)
MEANING
Connect the supplied power adapter to this jack.
Connect an UTP Ethernet cable to one of the four LAN
ports when connecting to a PC or an office/home network
of 10Mbps or 100Mbps.
Connect an UTP Ethernet cable to one of the four LAN
ports when connecting to a PC or an office/home network
of 10Mbps or 100Mbps.
There is one 2dBi Gain Antenna in the rear panel for
wireless connection.
A02-RB-W54
ENGLISH
30
