Digital Air Purifi er
LIST OF CONTENTS
10
13
ITEMS SUPPLIED
•
Air purifi er 1 x
•
Remote control incl. 3 V button cell
CR2025, already inserted 1 x
•
Operating instructions 1 x
Check the items supplied for complete-
ness and the components for transport
damage. If you fi nd any damage, do not
use the device but contact our customer
service department.
Remove any possible fi lms, stickers or
transport protection from the device.
Never remove the rating plate and
possible warnings!
Before using the remote control,
the protective strip has to be
removed from the battery com-
partment.
AT A GLANCE
Device
(Fig. A)
1 Control panel with display
2 Front cover
3 Combination fi lter (behind the front
cover)
4 Base
5 Main unit
6 Fan (in the main unit)
7 UV lamps (in the main unit)
8 Air vents (on the back)
9 Ventilation slots
09814_Inlay_DE-EN-FR-NL_A5_V1.indb 9
09814_Inlay_DE-EN-FR-NL_A5_V1.indb 9
9
9
10
11
11
14
15
15
16
16
10 Sensor for measuring air quality
11 Carrying handle (on the back)
Control panel
(Picture B)
12 Field ON / OFF
13 Field AUTO
14 Field SPEED
15 Field ION
16 Display
17 Field RESET
18 Field TIMER
19 Field SLEEP
20 Field CHILD LOCK
Display
(Fig. C)
21 Replace fi lter
22 Air purifi cation active
23 Fan activity
24 Particulate matter value
25 Current temperature
26 Timer setting
27 Child lock active
28 Ionisation active
29 AUTO mode active
30 Night mode active
31 Speed setting
32 Sterilisation active (UV light)
33 Air quality
Displays are shown as follows: XX
Key numbers are shown as follows: (1)
Picture references are shown as follows:
(Fig. A)
EN
14
14
9
31.07.2020 08:58:56
31.07.2020 08:58:56
