Voltage dips. short 0% Un for 0.5 cycle
interruptions 0 % Un for 1 cycle
and voltage
variations on power
supply input lines
IEC 61000-4-11
Power frequency
(50/60 Hz) magnetic
field
IEC 61000-4-8
Note: At 80 MHz and 800 MHz, the higher frequency range applies.
Note: These guidelines may not apply in all situations. Electromagnetic propagation is affected by
absorption and reflection from structures, objects and people.
a. Field strengths from fixed transmitters such as base stations for radio (cellular/cordless)
telephones and land mobile radios, amateur radio, AM and FM radio broadcast and TV broadcast
cannot be predicted theoretically with accuracy. To assess the electromagnetic environment due
to fixed RF transmitters, an electromagnetic site survey should be considered. If the measured field
strength in the location in which the R25C/R35C is used exceeds the applicable RF compliance level
above, the R25C/R35C should be observed to verify normal operation. If abnormal performance
is observed, additional measures may be necessary, such as re-orienting or relocating the R25C/
R35C.
b. Over the frequency range 150 kHz to 80 MHz, field strengths should be less than 3 V/m.
IEC 60601-1-2
Test level
70 % Un for 25
cycles
0 % Un for 5 s
30 A/m IEC 60601-1-2
Test level
Mains power quality should be
that of a typical commercial or
hospital environment. If the
user of the R25C/R35C requires
continued operation during
power mains interruptions. it is
recommended that the R25C/
R35C be powered from an
uninterruptible power supply
or a battery.
Power frequency magnetic
fields should be at levels cha-
racteristic of a typical location
in a typical commercial or ho-
spital environment.
