O
pening the garage door
If the function of the auxiliary push button is shared by all the telephones, all the auxiliary push
buttons must be connected in parallel, as shown in the following diagram:
FA-805
SEC
PRI
-
0 110220 ~2 ~1 +
Main
OPTIONAL CONNECTIONS
JP2
S+
JP2
S+
JP2
S+
Main door panel
L1 L2 BUS CV2 CV1 +12
T-7722VD
JP1
S- BUS HZ HZ PA PB
T-7722VD
JP1
S- BUS HZ HZ PA PB
T-7722VD
JP1
S- BUS HZ HZ PA PB
T-7722VD
JP2 JP1
S+ S- BUS HZ HZ PA PB
T-7722VD
JP2 JP1
S+ S- BUS HZ HZ PA PB
T-7722VD
JP2 JP1
S+ S- BUS HZ HZ PA PB
R-3
O B R T M
Activating the
garage door
