10 | English
ventilated area.
If the supply cord is damaged, it must be replaced
f
by the manufacturer, its service agent or similar-
ly qualified persons in order to avoid a hazard.
Do not operate the battery charger on easily
f
flammable surfaces (e.g., paper, textiles, etc.) or
surroundings. The heating of the battery charger
during the charging process can pose a fire hazard.
Do not cover the ventilation slots of battery
f
charger. Otherwise, the battery charger can over-
heat and no longer operate properly.

PRODUCT SPECIFICATIONS

INTENDED USE
The product is intended for cutting weed, grass or
similar soft vegetation in areas that are hard to reach,
e.g. under bushes, on slopes and edges. It may not be
used to work on unusual thick, dry or wet grass, e.g.
pasture grass, or to shred leaves. For safety reasons
it is essential to read the entire instruction manual
before its first operation and to observe all the in-
structions therein. This product is intended for pri-
vate domestic use only, not for any commercial trade
use. It must not be used for any purposes other than
those described.

TECHNICAL DATA

Article Number
Model
Rated voltage
No Load Speed
Cutting diameter
Cutting line thickness
Line length
Feed type
Run time
No load running time
Weight
Battery model
(not included)
Charger model
(not included)
Sound emission values determined according to
EN 60335-1, EN 50636-2-91, EN 62233
Typically the A-weighted noise levels of the product are:
Sound pressure level
Guaranteed sound
power level
Uncertainty K
42 405
BST 35/40V PLUS
V 36 (40max)
rpm 7.500
cm 33
Ømm 2
m 7
Auto feed
min 40
min 62
Kg 3,7
BLi 40V/5.0Ah
CH 40V/2A
dB(A) 79,4
dB(A) 96
dB 3
Vibration total values a
and uncertainty K determined according to EN
60335-1, EN 50636-2-91, EN 62233
Vibration level max:
a
h ,HD
K
IDENTIFICATION
1. Rear handle
2. Trigger
3. Safety button
4. Adjustable handle
5. Bolt
6. Handle lock
7. Rotating lock
8. Telescoping lock
9. Tube assembly
10. Housing with motor assembly
11. Safety guard
12. Cutter head assembly
13. Trimmer line
14. Cut-off blade
15. Edge guide
16. Screw
17. Battery (not included)
18. Battery release button
19. String casing
20. Internal spindle
21. Lid of the casing
ASSEMBLY
WARNING! Before using the product, famil-
iarize yourself with the operating features
read the entire instruction manual paying
particular attention to the safety rules and
operating procedures.
WARNING! The product must be fully assem-
bled before operation! Do not use a product
that is only partly assembled or assembled
with damaged parts! Follow the assembly in-
structions step-by-step and use the illustra-
tions provided as a visual guide to easily as-
semble the product! Do not connect the
battery pack to the product before it is com-
pletely assembled!
INSTALLING THE HANDLE (C)
Slide the front handle (4) into place and swivel it into
the desired position. Use the included bolt (5) and
handle adjustment knob (6) to secure it into place.
INSTALLING THE GUARD (B) AND EDGE GUIDE (E)
The safety guard (11) of the trimmer's head can be
f
installed with a single screw (16). Slide the guard into
place onto the head of the grass trimmer (10). On
the underside of the guard, right next to the spool
casing, there is a small screw hole. Attach the guard
in place by fastening the screw (16).
Once the guard has been put into place, attach the
f
edge guide (15) into the holes (15a) mounted on
either side of the front of the motor housing. The
guide requires slight stretching for installation, al-
BST 35/40V PLUS
(triax vector sum)
h
m/s 2,002
2
m/s 1,5
2
