Minimum Installation Clearances
15"
(381 mm)*
0" (0 mm) 0" (0 mm)
Recessed front view
*Additional clearances for wall, door and floor moldings may be required or if
external exhaust elbow is used.
48 in 2
(3.10 m 2 )*
Front
View
24 in 2
(1.55 m 2 )*
*Opening is the minimum for a closet door.
Louvered doors with equivalent air openings are acceptable.
6
14"
(356 mm)
max.
Closet
door
0"
(0 mm)
1" (25 mm)
Closet side view
3" (76 mm)
Closet
door
3" (76 mm)
Product Dimensions 27" (686 mm) dryer
27" (686 mm)
ELECTRIC
BACK VIEW
13"
6 3 ⁄ "
4
(330 mm)
(152 mm)
GAS
1 1 ⁄ "
4
(32 mm)
29 1 ⁄ " (743 mm)
4
26 1 ⁄ " (673 mm)
2
SIDE VIEW
35"
(889 mm)
LEFT OR
RIGHT SIDE
EXHAUST
3 ⁄ "
4
(21 mm)
7 1 ⁄ "
4
(184 mm)
14 1 ⁄ "
8
(359 mm)
14"
(356 mm)
37"
(940 mm)
4" (102 mm)
4 3 ⁄ "
4
dia.
(121 mm)
EXHAUST
Non-coin-
operated models:
7 1 ⁄ " (181 mm)
8
Coin-operated
models:
10 1 ⁄ "
4
7 7 ⁄ " (200 mm)
8
(260 mm)
4 1 ⁄ "
4
(108 mm)
BOTTOM
EXHAUST
