Installation

Installation
Read completely, then follow step by step.

Selection of the best location

• There should not be any heat source or steam near the unit.
• There should not be any obstacles to the air circulation.
• A place where air circulation in the room will be good.
• A place where drainage can be easily obtained.
• A place where noise prevention is taken into consideration.
• Do not install the unit near the door way.
• Ensure the spaces indicated by arrows from the wall, ceiling, or other obstacles.
• The indoor unit must have the maintenance space.
CAUTION : In case that the unit is installed near the sea, the installation parts
may be corroded by salt. The installation parts (and the unit) should be taken
appropriate anti-corrosion measures.
8 Indoor Unit
Ceiling
Ceiling Board
500(19- 11 / )
16
or more
Ceiling Board
500(19- 11 / )
16
or more
Unit:mm(inch)
Floor
