Configuration of channels and groups

Use the button (4) to configure the activator's operating mode.
Channel configuration: Keep the configuration button pressed down until the number of long red signals is equal to the channel to be configured. For example, if you want to configure
channel 2, release the button after the second long red signal.
Group configuration: Press the configuration button and keep it pressed down. The led will issue the red channel configuration signals followed by a series of flashing green signals to
indicate that the open group will start the group selection sequence (long green signals indicating groups 1 to 7). Release the button at the required group. For example, if you want to con-
figure group 5, release the button after the fifth long green signal.
The procedure can be carried out as many times as required.
Sequence for the configuration of channels and groups (example: channel 2, group 5)
•Channel 2 Configuration
•Group 5 Configuration
Channel: This allows for the channel to be sent to the receiver to be selected.
Group: This allows for the installation of more independently enabled doors (to a total of 22).
