Interpump Group Pralissoli R1503 Mode D'emploi page 4

Tav.B
DIMENSIONI D'INGOMBRO – OVERALL DIMENSIONS
DIMENSIONS D'ENCOMBREMENT - RAUMBEDARF
CODE DESCRIPTION
POS
CODICE DESCRIZIONE
1 083200210 Pastiglia conica tenuta ½"
44 084200090 Nipplo M-M G 1/2" - 1/4"
44 073200150 Nipplo M-M G 1/2" - 3/8"
44 084200580 Nipplo M-M G 1/2" – M14x1.5
44 084200590 Nipplo M-M G 1/2" – M20x1.5
44 084200600 Nipplo M-M G 1/2" – M22x1.5
44 084200550 Nipplo M-M G 1/2" – M24x1.5
45 084200220 Tappo G 1/2"
KIT RACCORDERIA – FITTINGS KIT
B
KIT 1104
C
KIT 1105
D
KIT 1106
E
KIT 1107
- -
4
KIT
B-C-D-E-F-G-H
C
D
E
F
G
H
F
KIT 1108
G
KIT 1109
H
KIT 1110
N.
PCS
1
1
1
1
1
1
1
1
