TRINQUETE NEUMÁTICO 3/8"
CLIQUET PNEUMATIQUE 3/8"
AIR
3
"
RATCHET
8
S P E C I F I C A T I O N S
Max. Torque ............................................................................. 100 ft. lbs.
Working Torque ......................................................................5-90 ft. lbs.
Max. Free Speed ....................................................................... 200 RPM
Air Inlet .......................................................................................1/4" NPT
Avg. Air Consumption ............................................................... 3.3 CFM
Sound Pressure Level.................................................................. 88 dBA
Recommended Air Pressure ......................................................90 PSIG
Air Hose Size ................................................................................. 3/8" ID
Length ............................................................................................... 10.2"
Weight ......................................................................................... 2.5 LBS.
WARNING
ALWAYS READ
INSTRUCTIONS
BEFORE USING
POWER TOOLS
ALWAYS WEAR
SAFETY
GOGGLES
ALWAYS WEAR
HEARING
PROTECTION
AVOID
PROLONGED
EXPOSURE TO
VIBRATION
Some dust created by power sanding, sawing, grinding, drilling, and other
construction activities contains chemicals known to cause cancer, birth defects or
other reproductive harm. Some examples of these chemicals are:
• lead from lead-based paints,
• crystalline silica from bricks and cement and other masonry products, and
• arsenic and chromium from chemically-treated lumber.
Your risk from these exposures varies, depending on how often you do this type
of work. To reduce your exposure to these chemicals: work in a well ventilated
area, and work with approved safety equipment, such as those dust masks that are
specially designed to filter out microscopic particles.
MT2854
WARNING
Copyright © Professional Tool Products, 2016
MT2854
• Operating Instructions
• Warning Information
• Parts Breakdown
All rights reserved
Publicité
Table des Matières
Manuels Connexes pour Matco Tools MT2854
Sommaire des Matières pour Matco Tools MT2854
- Page 1 MT2854 • Operating Instructions • Warning Information TRINQUETE NEUMÁTICO 3/8" • Parts Breakdown CLIQUET PNEUMATIQUE 3/8" " RATCHET S P E C I F I C A T I O N S MT2854 Max. Torque ................100 ft. lbs. Working Torque ..............5-90 ft. lbs.
- Page 2 Secure long hair. Scalping can occur if hair is not kept away from tool and or not legible, contact Matco Tools for replacements. If the operator is not fluent in English, the product accessories. Choking can occur if neckwear is not kept away from tool and accessories.
-
Page 3: Air Supply
Always turn off the air supply, drain hose of air pressure and detach tool from air supply before installing, removing or The MT2854 3/8" ratchet is designed to fasten and unfasten adjusting any part or accessory on this tool, or before performing threaded fasteners while operating under recommended any maintenance on this tool. - Page 4 Matco be liable for any incidental or consequential damages. Note: Some states do not allow the exclusion or limitation of incidental or consequential damages so the above limitation or exclusion may not apply to you. MT2854 rev. 04/08/16...
- Page 5 MT2854 3/8" Air Ratchet ITEM PART NO. DESCRIPTION QTY. ITEM PART NO. DESCRIPTION QTY. RS285401 Air Inlet RS285427 Gear Plate RS285402 Valve Spring RS285428 Clamp Nut RS285403 Valve RS285429 Bushing RS285404 Valve Seat RS285430 Ratchet Housing RS285405 Valve Washer RS285431...
- Page 6 MT2854 • Instrucciones de Operación TRINQUETE NEUMÁTICO 3/8" • Inforación de Advertencia • Revisión de Refacciones CLIQUET PNEUMATIQUE 3/8" " RATCHET E S P E C I F I C A C I O N E S MT2854 Torsión Máxima ...............100 Libras-pie.
- Page 7 El trinquete MT2854 3/8" está diseñado para sujetar y de-sujetar Apague siempre el suministro de aire, vacíe la manguera de cierres roscados, al momento de operarlo bajo las condiciones su presión de aire y desconecte la herramienta del suministro...
-
Page 8: Características
MT2854 Trinquete neumático 3/8" CARACTERÍSTICAS • Disparador preciso de velocidad variable para un mayor control. • Disminuye el nivel sonoro con un sistema de escape bicameral. (Patente en trámite). • Dirija el aire lejos del trabajo usando el escape giratorio de 360 grados. - Page 9 La obligación anterior es la única responsabilidad de Matco 22 Goodmark Place Unit #8 Toronto, ON M9w 6R2 bajo esta o cualquier garantía implicada y Matco no será, bajo (416) 213-0172 ninguna circunstancia, responsable por los daños incidentales ni consecuenciales. MT2854 rev. 04/08/16...
- Page 10 MT2854 • Instructions de TRINQUETE NEUMÁTICO 3/8" fonctionnement • Avertissement CLIQUET PNEUMATIQUE 3/8" • Pièces " RATCHET S P É C I F I C A T I O N S MT2854 Vitesse max. en regime libre ..........100 ft. lbs.
- Page 11 MT2854 Cliquet pneumatique 3/8" AVERTISSEMENT LE NON-RESPECT DE CES AVERTISSEMENTS POURRAIT ENTRAÎNER DES BLESSURES. • Calculez vos mouvements et prenez garde aux CE GUIDE D’UTILISATION RENFERME changements brusques de position quand vous utilisez un D’IMPORTANTES CONSIGNES DE SÉCURITÉ. LISEZ CE GUIDE D’UTILISATION outil électrique.
-
Page 12: Caractéristiques
REMARQUE : Lors de l’utilisation, toujours porter des lunettes de sécurité pour protéger les yeux contre les décombres (utilisateur et personnes à proximité). The MT2854 3/8" ratchet is designed to fasten and unfasten threaded fasteners while operating under recommended conditions. Note the directional setting of the reversing lever before depressing the throttle. -
Page 13: Dépannage
MT2854 Cliquet pneumatique 3/8" SOURCE D’ALIMENTATION EN AIR DÉPANNAGE D'autres facteurs en dehors de l'outil peuvent provoquer une perte Les outils de cette catégorie fonctionnent avec un large éventail de puissance ou une action erratique. Sortie du compresseur réduit, de pressions d'air. Nous recommandons une pression d'air à...
