Addressing
Factory preset is 0.
Addressing with the addressing unit AC1154
The mounted and wired module can be addressed with the addressing
cable (E70213) via the addressing socket.
Only address via the addressing socket when disconnected.
If a slave with the ID code "A" (extended addressing mode pos-sible)
is used with a master of the first generation (version 2.0), the parame-
ter P3 must be 1 and the output bit D3 = 0*. The output bit D3 must
not be used.
If a slave with the ID code "A" (extended addressing mode pos-sible)
is used with a master of the first generation (version 2.0), an address
between 1A and 31A must be assigned to this slave.
* default setting
Operation
Check the safe functioning of the unit. Display by LEDs:
• LED green: voltage supply via the AS-i network o.k.
• LED yellow: input / output switched
• LED red is lit: AS-i communication error, e. g. slave address 0
• LED red flashing: peripheral fault, e.g. input overloaded

Technical data

You can download the data sheet from the Internet if required
(www.ifm.com).
