HYGRASREG AH - 30
Electronic on-wall hygrostats and humidity sensors HYGRASREG
optional with or without display indicating the actual humidity, accuracy class ± 3 % r. H. They are used to control and monitor the relative humidity,
e.g. in venti lation and air conditioning ducts, laboratories, production facilities, climatic test cabinets, indoor swimming pools, greenhouses, etc. to control
humidifying and dehumidifying equipment. These measuring transducers are designed for exact humidity measurement. HYGRASREG
long-term stable sensor as measuring element for humidity measurement. Applications in dust-free, pollutant-free, non-aggressive air.
TECHNICAL DATA:
Power supply: ........................ 24 V AC ⁄ DC (optional 230 V AC via external power supply unit)
Power consumption: ................ < 2 VA ⁄ 24 V DC
Setting range: ....................... 5 ... 95 % r. H. (switch steps 1 and 2 are separately adjustable)
Operating difference: ............... Mode 1: both switch steps are arbitrary adjustable
Output: ................................. potential-free changeover contacts (2 x changeover contact 24 V,
Sensors: ............................... digital humidity sensor
Deviation, humidity: ................. ± 3 % r. H. (20...90 %); at + 20 °C, otherwise ± 5 % r. H.
Long-term stability:................. ± 1 % per year
Hysteresis: ............................ max. 3 % r. H.
Sensor protection: .................. membrane filter, exchangeable
Enclosure temperature: ........... - 10 °C ...+ 65 °C
Enclosure: ............................. plastic, material polyamide, 30 % glass-globe-reinforced,
Enclosure dimensions: ............. 108 x 70 x 73.5 mm (Thor II)
Cable gland: ........................... M 16 x 1.5 ; including strain relief
Flow rate: ............................. max. 8 m ⁄ s
Protective tube: ..................... metal, Ø 20 mm, nominal length NL = 103 mm
Protection class: .................... III (according to EN 60 730)
Protection type: ..................... IP 65 (according to EN 60 529)
Electrical connection: ............. 0.14 - 2.5 mm
Standards: ............................ CE conformity, EMC directive 2004 ⁄ 108 ⁄ EC
Optional: ............................... Single-line display, shifting, 36 x15 mm (W x H), for displaying ACTUAL
FUNCTION:
Humidifying: .............................. 1
Dehumidifying: .......................... 1
Type ⁄ WG2 Setting Range
Humidity
AH - 30
A H - 3 0 W 5 ... 95 % r. H.
A H - 3 0 W_ D I S P L AY 5 ... 95 % r. H.
Extra charge for 230 V AC supply voltage via external power supply unit
® AH-30 with one continuous and two switching outputs, adjustable switching thresholds,
Mode 2: 5 % between both switch steps
separately adjustable, 1x 0 - 10 V ^ = 0 - 100 % r. H.)
with quick-locking screws (slotted ⁄ Phillips head combination),
colour pure white (similar RAL 9010)
2
, via terminal screws
humidity respectively for humidity setpoint adjustment
st step: wire contacts 4 - 5.
When actual humidity falls more than 3 % r. H. (hysteresis)
below switching threshold S1, changeover contact switches to 4 - 5.
nd
2 step: wire contacts 7 - 8.
When actual humidity falls more than 3 % r. H. (hysteresis)
below switching threshold S 2, changeover contact switches to 7 - 8.
Terminal 2: 1x 0 - 10 V equivalent to 0...100 % r. H.
st
step: wire contacts 5 - 6.
When actual humidity exceeds switching threshold S 1,
changeover contact switches to 5 - 6.
nd
2 step: wire contacts 8 - 9.
When actual humidity exceeds switching threshold S 2,
changeover contact switches to 8 - 9. Terminal 2: 1x 0 - 10 V ^ = 0 - 100 % r. H.
Output
2 x Changeover contact, 1x 0 -10 V
2 x Changeover contact, 1x 0 -10 V
Steps Display Item No.
External setting
two-step 1202-1036- 1011- 000
two-step ■ 1202-1036-1111- 000
® AH-30 uses a digital
