Functional Description

Intended Use

The measuring tool is intended for measuring distances,
lengths, heights, clearances, and for the calculation of areas
and volumes. The measuring tool is suitable for measuring
indoors and outdoors.

Product Features

The numbering of the product features shown refers to the
illustration of the measuring tool on the graphic page.
1 Length measurement button
2 Memory add button "M+"
3 Button for area and volume measurement
4 Memory retrieve button "M="
5 Button for indirect length measurement
6 Tracking (continuous measurement) button
7 On/Off and memory delete button
8 Memory subtraction button "M–"
9 Button for selection of the reference level
10 Display
11 Alignment aid
12 Measuring button
13 Laser warning label
14 Positioning pin
15 Latch of the positioning pin
16 Spirit level
17 Latch of battery lid
18 Battery lid
19 Laser beam outlet
20 Reception lens
21 Serial number
22 Laser viewing glasses*
23 Carrying strap
24 Laser target plate*
25 Protective pouch
* The accessories illustrated or described are not included as
standard delivery.
